LevelOne GEP-2651 / Switch / smart / 24 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP / rack-mountable / PoE+ (185 W) | GEP-2651
LevelOne GEP-2651 / Switch / smart / 24 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP / rack-mountable / PoE+ (185 W) | GEP-2651
€878.11 inc. VAT
GEP-2651
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
LevelOne GEP-2651 / Switch / smart / 24 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP / rack-mountable / PoE+ (185 W) | GEP-2651
Description
GEP-2651 web smart Gigabit PoE switch is an Ethernet switch, offering powerful L2 features, Layer 3 static route, better PoE functionality and usability, that delivers the cost-effectively business and transports Ethernet services via fiber or copper connections. GEP-2651 delivers 24 RJ-45/PoE+ ports and 2 combo GbE RJ-45/SFP ports. GEP-2651 provides high HW performance and environment flexibility for SMBs and enterprises. GEP-2651 is ideal to deliver management simplicity, optimum user experience, and lower total cost of ownership. The embedded device managed system is designed to be extremely easy-to-use/manage/install IP phone, IP am, or Wi-Fi-AP for Enterprise applications.
LevelOne GEP-2651 / Switch | GEP-2651
Special Features
- 24 PoE-Plus Gigabit Ethernet ports and 2 Gigabit SFP slots
- QoS control for traffic prioritization and bandwidth management
- DHCP client/server
- Supports IPv4/IPv6 network operation
- Minimize carbon footprint with advanced energy-efficient technology (IEEE 802.3az)
- IEEE 802.1d/w/s Spanning Tree Protocol (STP) and port mirroring
- IP multicast filtering through IGMP snooping V1/V2/V3
- Supports port-based VLAN, IEEE 802.1Q VLAN tagging
- IEEE 802.3ad LACP for auto port aggregation
Product Specification
| Device Type | Switch - 26 ports - smart |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Gigabit Ethernet |
| Ports | 24 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 185 W |
| Performance | Switching capacity: 52 Gbps ¦ Forwarding performance: 38.7 Mpps |
| Capacity | Active VLANs: 256 ¦ Virtual interfaces (VLANs): 4096 |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9600 bytes |
| Routing Protocol | IGMPv2, IGMP, IGMPv3 |
| Remote Management Protocol | RMON 1, RMON 2, SNMP, RMON 3, RMON 9, HTTP |
| Features | Trunking, VLAN support, IGMP snooping, Syslog support, port mirroring, store and forward, IPv6 support, firmware upgradable, Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, Multiple Spanning Tree Protocol (MSTP) support, DHCP snooping, Access Control List (ACL) support, Quality of Service (QoS), DHCP server, reset button, STP Root Guard, IPv4 support, LLDP support, DHCP client, Energy Efficient Ethernet, tagged VLAN, Bridge protocol data unit (BPDU), Network Timing Protocol (NTP) |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.3at, IEEE 802.3az |
| RAM | 128 MB |
| Flash Memory | 32 MB |
| Status Indicators | Port transmission speed, system, PoE, link/activity |
| Interfaces | 24 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-X SFP ¦ 2 x 1000Base-T RJ-45 |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 18.29 Watt |
| MTBF | 211,272 hours |
| Width | 44.2 cm |
| Depth | 21.1 cm |
| Height | 4.4 cm |
| Weight | 3.1 kg |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Min Storage Temperature | -20 °C |
| Max Storage Temperature | 70 °C |
| Humidity Range Storage | 10 - 90% (non-condensing) |
Features - LevelOne - GEP-2651
General
24-Port
More Details
Product Code
04:210171
EAN Code
4015867198957
Manufacturer
LevelOne
