LevelOne GEU-0523 5-Port Gigabit Ethernet Switch - Unmanaged
The LevelOne GEU-0523 is a compact unmanaged Gigabit Ethernet switch with 5 RJ-45 ports. It is designed for straightforward desktop or wall-mounted network expansion, with a black metal housing and an external power adapter.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Switch - 5 ports - unmanaged |
| Interfaces | 5 x 1000Base-T RJ-45 |
| Ports | 5 x 10/100/1000 |
| Switch Type | Unmanaged |
| Sub-Type | Gigabit Ethernet |
| Enclosure Type | Desktop, wall-mountable |
| Housing Material | Metal |
| Colour | Black |
| Power | External power adapter |
| Power Supply Included | No |
| DC Input Voltage | 5 V |
| Input Current | 0.5 A |
| Switching Capacity | 10 Gbit/s |
| Backplane Speed | 10 Gbps |
| Packet Forwarding Rate | 1488000 pps |
| MAC Address Table | 2000 entries |
| Jumbo Frames Support | Yes |
| Jumbo Frames | 9000 |
| Features | Energy Efficient Ethernet |
| Networking Standards | IEEE 802.3az |
| MAC Address Auto-Learning | Yes |
| MAC Address Auto-Aging | Yes |
| Processor Model | MT7530D |
| Built-In Processor | Yes |
| RAM | 8 KB |
| Flash Memory | 1024 MB |
| Status Indicators | Power, link/activity |
| LED Indicators | Yes |
| PoE | No |
| 10G Support | No |
| Transmission Method | Store-forward |
| Dimensions | 124 x 72 x 24 mm |
| Weight | 174 g |
| Wall Mountable | Yes |
| Rack Mounting | No |
| Country of Origin | China |
| SKU / EAN | GEU-0523 | 4015867222256 |
SINGULAR RECOMMENDS
For who
Suitable for home or small office users who need a simple 5-port Gigabit switch with no setup required.
Real reason to buy it
A straightforward unmanaged Gigabit switch with all 5 ports at 10/100/1000 speeds, plus desktop or wall-mount flexibility.
Know before
This model is unmanaged and does not include PoE. A power supply is not included in the spec data; the listing shows an external power adapter and AC adapter included.
Features - LevelOne - GEU-0523
Standard
5-Port
Port Speed
- 1 Gbps
More Details
Product Code
04:322834
EAN Code
4015867222256
Manufacturer
LevelOne
