LevelOne POI-3004 Gigabit PoE+ Injector 30W, IEEE 802.3af/at, 1 Port, 6kV Surge Protection, Internal Power Supply, Black

Brand:
LevelOne
LevelOne POI-3004 Gigabit PoE+ Injector 30W
LevelOne POI-3004 Gigabit PoE+ Injector 30W, IEEE 802.3af/at, 1 Port, 6kV Surge Protection, Internal Power Supply, Black
€95.43 inc. VAT
Buy
POI-3004
€80.19
€95.43 inc. VAT
Ships from EU stock: 81 item(s)
+ −
Add to wish list Ask a question
Product Code
04:156113
EAN Code
4015867187821
Manufacturer
LevelOne

Quick Specs

Type
PoE+ injector, 1 port
Connectors/Interface
RJ45 Data IN + PoE OUT, Gigabit
Key spec
30W · 6kV surge
Compatibility
802.3af/at devices
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

LevelOne POI-3004 — add 30 W PoE+ to any Gigabit port

802.3af/at · 30WGigabit6kV surge protectionPower cord included

The LevelOne POI-3004 is a single-port Gigabit PoE+ injector that adds up to 30 W of IEEE 802.3af/at power to a normal Ethernet cable, so one IP camera, access point or VoIP phone can run up to 100 m away without its own adapter. It is the simplest fix when your switch has no PoE, or no free PoE port.

Connect the switch to the data port, the device to the PoE port and the injector to the mains. The power supply is built in and a power cord is in the box.

Before you order: The POI-3004 sends power on the spare pairs (pins 4/5 +, 7/8 −). Standard 802.3af/at devices accept this, but some non-standard or passive-PoE devices expect power on the data pairs — check older or very low-cost equipment.

What's in the Box

  • LevelOne POI-3004 Gigabit PoE Injector
  • Quick Installation Guide
  • Power cord
  • No network cables

What It Means in Practice

  • Up to 30 W covers typical dome and bullet cameras, dual-band access points and desk phones.
  • Gigabit pass-through keeps full speed for access points and cameras.
  • 6 kV surge protection adds a margin for cameras on outdoor runs.
  • Interlocking housings let several injectors sit neatly side by side, and the unit can be wall-mounted.

What Will Not Work

  • 802.3bt devices that need more than 30 W (PTZ with heaters, Wi-Fi 7 high-power APs) will not run fully.
  • It powers one device only.
  • No 2.5G/5G/10G pass-through — 10/100/1000 Mbps only.
  • Passive 24 V PoE devices are not supported.

Key Features


802.3af/at PoE+
Up to 30 W on one port.

Gigabit data
10/100/1000 Mbps pass-through.

6 kV surge protection
High-level protection against voltage spikes.

Interlocking design
Several units mount neatly together; wall-mountable.

Technical Specifications

Identification
Part Number POI-3004
Brand LevelOne
Ports & Network
Ports 2x Gigabit RJ45 (1 data in, 1 PoE out)
Data rate 10/100/1000 Mbps
Standards IEEE 802.3, 802.3u, 802.3ab, 802.3af/at
Pin assignment 4/5 (+), 7/8 (−)
Distance Up to 100 m
Power
PoE output Up to 30 W
Power supply Internal, power cord included
Protection 6 kV surge
Physical
LEDs Power, PoE
Colour Black
Dimensions 143 x 51 x 38 mm
Weight 0.35 kg
Mounting Wall mount, interlocking
Operating temperature -20–60 °C
Humidity 5–95% RH
Certifications CE, FCC, UL
Warranty
Warranty 1-Year Warranty (Singular)
Manufacturer Term Manufacturer does not publish a warranty term — claims handled through Singular

Frequently Asked Questions

Will it power a PoE (802.3af) phone?
Yes. 802.3af devices draw up to 15.4 W, well within the 30 W limit.
Do I need a special switch?
No. Any Ethernet switch or router port works; the injector adds the power.
Why does the pin assignment matter?
Standard PoE devices accept power on either pair set. Only some non-standard devices need power on pins 1/2 and 3/6 — tell us the model if unsure.
Singular Expert Insight · Buyer's Guide
An inexpensive way to add one PoE+ IP camera or access point to a network without changing the switch. For more than three or four devices, a PoE switch is usually cheaper per port and tidier.
✓ Buy it if you need to power one 802.3af/at device up to 30 W from a non-PoE port.
✕ Skip it if the device needs 802.3bt power or Multi-Gig speed.
→ Also consider LevelOne POI-3000 (same 30 W class) or TRENDnet TPE-219GI for 90 W and 2.5G.
Send us the camera or access point model and we will confirm it runs within 30 W.
