LevelOne GTL-2091 20-Port L3 Managed Gigabit Switch - 12x 10G SFP+
The LevelOne GTL-2091 is a 20-port L3 managed Gigabit switch for rack or desktop installation. It combines 8 x 1000Base-T RJ-45 ports with 12 x 10G SFP+ ports, and includes dual power redundancy, making it suitable for structured network deployments that need flexible fibre and copper connectivity.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Switch - 20 ports - L3 - Managed |
| Interfaces | 8 x 1000Base-T RJ-45 | 12 x 10Gbit LAN SFP+ | 1 x console RJ-45 | 8 x 1000Base-T RJ-45 12 x 10Gbit LAN SFP+ 1 x console RJ-45 |
| Enclosure Type | Desktop, rack-mountable 1U |
| Subtype | 10 Gigabit Ethernet |
| Switching Capacity | 256 Gbps |
| MAC Address Table Size | 32K entries |
| Jumbo Frame Support | 9KB |
| Routing Protocol | RIP-1 | RIP-2 | BGP | VRRP | OSPFv2 | PIM-SM | PIM-DM | OSPFv3 | static IPv4 routing | static IPv6 routing |
| Remote Management Protocol | SNMP 1 | RMON 1 | RMON 2 | Telnet | SNMP 3 | SNMP 2c | HTTP | TFTP | CLI |
| Encryption Algorithm | SSL |
| Authentication Method | RADIUS | Secure Shell v.2 (SSH2) |
| Features | Flow control | VLAN support | IGMP snooping | DoS attack prevention | port mirroring | store and forward | IPv6 support | full duplex mode | STP support | RSTP support | MSTP support | ACL support | QoS | DHCP server | reset button | IPv4 support | DHCP relay | DHCP client | CoS | NTP | Root Guard | Loop Guard | EEE | 3Mbit packet buffer |
| Compliant Standards | IEEE 802.3 | IEEE 802.3z | IEEE 802.1D | IEEE 802.1Q | IEEE 802.1p | IEEE 802.3x | IEEE 802.3ad (LACP) | IEEE 802.1w | IEEE 802.1x | IEEE 802.3ae | IEEE 802.1s | IEEE 802.1ad | IEEE 802.3ah | IEEE 802.1ag | IEEE 802.3az | IEEE 802.1AX |
| RAM | 512 MB |
| Flash Memory | 16 MB |
| Status Indicators | Power | system | link/activity |
| Power Device | Internal power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Power Provided | 50 Watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Included Accessories | Rubber feet |
| Cables Included | 1 x console cable |
| Rack Mounting Kit | Included |
| Weight | 3.6 kg |
| Width | 44 cm |
| Depth | 31.5 cm |
| Height | 4.4 cm |
| Power | Internal power supply |
| Package Contents | Rubber feet |
| Security | SSL |
| Management Protocol | SNMP 1, RMON 1, RMON 2, Telnet, SNMP 3, SNMP 2c, HTTP, TFTP, CLI |
| SKU / EAN | GTL-2091 | 4015867208366 |
SINGULAR RECOMMENDS
For who
For network installers and businesses that need a managed 20-port switch with 10G SFP+ uplinks, L3 routing and rack mounting.
Real reason to buy it
It brings 12 x 10G SFP+ ports, L3 managed routing and dual power redundancy into a compact 1U design.
Know before
The switch is supplied with rubber feet and a console cable, and the rack mounting kit is included. Power is via an internal AC supply, and the product is not a fanless desktop unit.
