LevelOne POW-2432 Industrial DIN-Rail Power Supply 24V DC 3.2A 75W Universal 90-264V AC Input Fanless -20 to 70 C DC OK Relay

Brand:
LevelOne
LevelOne POW-2432 24V 75W DIN-Rail Power Supply
LevelOne POW-2432 Industrial DIN-Rail Power Supply 24V DC 3.2A 75W Universal 90-264V AC Input Fanless -20 to 70 C DC OK Relay
€77.46 inc. VAT
Buy
POW-2432
€65.09
€77.46 inc. VAT
Ships from EU stock: 23 item(s)
+ −
Add to wish list Ask a question
Product Code
04:461563
EAN Code
4015867236567
Manufacturer
LevelOne

Quick Specs

Output
24 V DC, 3.2 A (75 W)
Input
90–264 V AC / 127–370 V DC
Temperature
−20 to +70 °C, full load
Mounting
35 mm DIN rail, fanless
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

LevelOne POW-2432 — 24 V, 75 W DIN-rail PSU

24 V / 3.2 A75 W−20 to +70 °CDC OK relay

The LevelOne POW-2432 is a 24 V DC industrial power supply that delivers 75 W (3.2 A) on a standard 35 mm DIN rail. It accepts a universal 90–264 V AC or 127–370 V DC input, runs fanless, and LevelOne rates it for continuous operation from −20 to +70 °C with 100% full load. The output can be adjusted between 24 and 28 V, a DC OK relay contact reports status to a monitoring system, and short-circuit, overload and over-voltage protection guard the supply and the load. Each unit is burn-in tested. In practice it powers 24 V industrial switches, controllers and sensors in cabinets, including unconditioned outdoor enclosures.

Compatibility — check before buying:
For installation by a qualified person — screw terminals and an earth connection; it has no mains plug. It outputs 24 V: to power PoE switches that need 48–57 V, choose a 48 V model such as the LevelOne POW-4821. LevelOne also sells an older 24 V 75 W model, POW-2431 — check which one your design calls for. Not sure? Tell us your model and we check it for you.

Best For

✓ 24 V industrial PoE switches
✓ Control cabinets
✓ Factory automation
✓ Outdoor and unconditioned enclosures
✓ PLCs, sensors and actuators
✓ Access control panels

Key Features


75 W at 24 V
3.2 A, adjustable 24–28 V.

Wide temperature
−20 to +70 °C at 100% load.

Universal input
90–264 V AC or 127–370 V DC.

Fanless + DC OK
Silent convection cooling and status relay.

Technical Specifications

Identification
Brand LevelOne
Product POW-2432 24V DC Industrial Power Supply, 75W, DIN-Rail
Part Number POW-2432
EAN / GTIN 4015867236567
Product Type Industrial DIN-rail power supply
Output
Voltage 24 V DC
Rated current 3.2 A (range 0–3.2 A)
Rated power 75 W
Adjustment range 24–28 V
Ripple & noise (max.) 150 mVp-p
Voltage tolerance ±1.0%
Line regulation ±0.5%
Load regulation ±1.0%
Setup, rise time 1200 ms, 60 ms / 230 V AC at full load
Hold-up time (typ.) 16 ms / 230 V AC at full load
Input
AC input 90–264 V AC, 47–63 Hz
DC input 127–370 V DC
AC current (typ.) 1.45 A / 115 V AC, 0.9 A / 230 V AC
Inrush current (typ.) 20 A / 115 V AC, 35 A / 230 V AC
Leakage current <1 mA / 240 V AC
Protection & Signals
Protections Short circuit, overload, over-voltage
Over-voltage 29–33 V
Status DC OK relay contact
Testing Burn-in tested
Environment & Compliance
Operating temperature −20 to +70 °C, 100% full load
Operating humidity 0–90% RH
MTBF 486.2K hours min.
EMC EN 55032 (CISPR32) Class A, EN 61000-3-2/-3, EN 61000-4-2,3,4,5,6,8,11, EN 61204-3, EN 55035, EN 61000-6-2
Physical
Dimensions (W × D × H) 32 × 102 × 125.2 mm
Weight 0.43 kg
Mounting 35 mm DIN rail
Cooling Fanless
Colour Silver
In the Box
Included Power supply
Not Included DIN rail; mains cable; fuse or circuit breaker
Warranty
Warranty 1-Year Warranty (Singular)
Manufacturer Term LevelOne does not publish a warranty term for this item on its product page. Singular’s direct warranty is 1 year, and we support you locally for anything beyond it.

Frequently Asked Questions

Can it power a PoE switch?
Only switches that accept 24 V input. For 48 V PoE switches use the POW-4821.
Does it work in a hot cabinet?
LevelOne rates it for −20 to +70 °C at full load.
Can I adjust the output?
Yes, from 24 to 28 V.
Can I install it myself?
It must be wired by a qualified person, with earth.
Singular Expert Insight
Industrial switches often accept 12–57 V DC, but PoE output needs 48 V or more — check before choosing 24 V. For 24 V controllers and sensors the POW-2432 is a solid, fanless choice. For industrial switches, see our PoE switches.

Buyer’s Guide

Buy it if

You need 24 V, up to 75 W, on a DIN rail in a cabinet.

Skip it if

Your load needs 48 V for PoE.

Also consider

LevelOne POW-4821 — 48 V, 75 W.
