LevelOne POW-4842 Industrial DIN Rail Power Supply 48V DC 2.5A 120W Wide Temperature -20 to 70 C Fanless DC OK Relay 90-264V AC

Brand:
LevelOne
LevelOne POW-4842 48V 120W DIN Rail PSU Wide Temp
LevelOne POW-4842 Industrial DIN Rail Power Supply 48V DC 2.5A 120W Wide Temperature -20 to 70 C Fanless DC OK Relay 90-264V AC
€99.9 inc. VAT
Buy
POW-4842
€83.95
€99.90 inc. VAT
Ships from EU stock: 6 item(s)
+ −
Add to wish list Ask a question
Product Code
04:461569
EAN Code
4015867236604
Manufacturer
LevelOne

Quick Specs

Output
48 V DC, 2.5 A (120 W)
Input
90–264 V AC / 127–370 V DC
Temperature
−20 to +70 °C
Signal
DC OK relay
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

POW-4842 — 48 V, 120 W DIN rail PSU

48 V / 120 W−20 to 70 °CFanlessDC OK relay

The LevelOne POW-4842 is a wide-temperature 48 V DC industrial power supply that delivers 120 W (2.5 A) on a 35 mm DIN rail. It runs continuously from −20 to +70 °C, accepts 90–264 V AC or 127–370 V DC, and is fanless. Short-circuit, overload and over-voltage protection guard the supply and the equipment, each unit is burn-in tested, and a DC OK relay contact reports status. In practice it powers 48 V equipment such as industrial PoE switches and injectors in unheated cabinets and outdoor enclosures.

Compatibility — check before buying:
For installation by a qualified person — screw terminals, earth connection required. The output is adjustable 48–55 V. The sibling POW-4841 has the same output but is rated to +60 °C and has no DC OK relay listed. For 24 V equipment you need a 24 V supply. Not sure? Tell us your model and we check it for you.

Best For

✓ Industrial PoE switches
✓ PoE injectors in cabinets
✓ Outdoor enclosures
✓ Unheated cabinets
✓ Factory automation
✓ Remote monitoring (DC OK)

Key Features


120 W at 48 V
2.5 A, adjustable 48–55 V.

Wide temperature
−20 to +70 °C operation.

DC OK relay
Signals output status to monitoring systems.

Fanless
Silent, no fan to fail.

Technical Specifications

Identification
Brand LevelOne
Product POW-4842 48V DC Industrial Power Supply, 120 W, wide temperature
Part Number POW-4842
EAN / GTIN 4015867236604
Product Type Industrial DIN rail power supply, wide temperature
Output
Voltage 48 V DC (adjustable 48–55 V)
Rated current 2.5 A
Rated power 120 W
Ripple & noise 150 mVp-p
Tolerance ±1.0%
Hold-up time 16 ms / 230 V AC
Input
AC 90–264 V AC, 47–63 Hz
DC 127–370 V DC
AC current 2.25 A / 115 V AC, 1.3 A / 230 V AC
Inrush current 20 A / 115 V AC, 35 A / 230 V AC
Protection
Protections Short circuit, overload, over-voltage
Over-voltage 56–65 V
Signal DC OK relay contact
Environment
Operating temperature −20 to +70 °C
Humidity 20–95% RH
Storage −40 to 85 °C
EMC EN 55032 Class A, EN 55035, EN 61000-6-2, EN 61204-3
MTBF 2636.8K h (Telcordia)
Physical
Dimensions 40 × 113.5 × 125.2 mm
Weight 0.53 kg
Mounting 35 mm DIN rail
Cooling Fanless
Colour Silver
In the Box
Included POW-4842 power supply
Not Included DIN rail; mains cable; fuse or breaker
Warranty
Warranty 1-Year Warranty (Singular)
Manufacturer Term LevelOne does not publish a warranty term for this item on its product page or datasheet. Singular’s direct warranty is 1 year, and we support you locally for anything beyond it.

Frequently Asked Questions

What voltage does it output?
48 V DC at up to 2.5 A (120 W), adjustable 48–55 V.
Can it run at high temperatures?
Yes, up to +70 °C.
What is the DC OK relay?
A contact that signals whether the output is present.
Can I install it myself?
It must be wired by a qualified person.
Singular Expert Insight
For PoE, remember the switch or injector needs 48–55 V; a 48 V supply set a little higher gives full PoE+ power. Size with 20–30% headroom. For industrial switches, see our PoE switches.

Buyer’s Guide

Buy it if

You need 48 V, 120 W in a hot or unheated cabinet.

Skip it if

Your cabinet is climate-controlled (POW-4841 suffices).

Also consider

LevelOne POW-4841 — 48 V, 120 W, to +60 °C.
