LevelOne POI-3014 / PoE injector (wall mountable) / AC 100-240 V / 30 Watt | POI-3014
Please sign in so that we can notify you about a reply
Special Features
- Remove the need for a bulky power adapter and power line
- Delivers power and data to equipment via a single Ethernet cable
- Remote power feeding up to 100m
- Unique interlocking feature for easy installation
- Surge protected to enhance safety
- Simple Plug and Play installation
- Compact, lightweight design
- Total PoE power budget: 30W, up to 30W per port
Product Specification
| Device Type | PoE injector - wall mountable |
| Power Device | Power Device |
| Input Voltage | AC 100-240 V |
| Frequency Required | 50/60 Hz |
| Power Output Connectors Details | 1 x RJ-45 - 52 V 0.6 A |
| Output Voltage | DC 52 V |
| Power Capacity | 30 Watt |
| Surge Suppression | Yes |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Gigabit LAN - RJ-45 |
| Miscellaneous | Miscellaneous |
| MTBF | 87,100 hours |
| Features | LED indicators |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, Plug and Play, FCC Part 15, RoHS |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 6.439 cm |
| Depth | 4.34 cm |
| Height | 14.57 cm |
| Weight | 350 g |
Features - LevelOne - POI-3014
More Details
Product Code
04:335590
EAN Code
4015867223185
Manufacturer
LevelOne
