LevelOne Managed Gigabit Media Converter RJ45 to SC Multi-Mode Fiber, up to 500 m, 850 nm, OAM, Web/SNMP, Black
Brand:
LevelOne
LevelOne Managed Gigabit Media Converter RJ45 to SC Multi-Mode Fiber, up to 500 m, 850 nm, OAM, Web/SNMP, Black
€263.14 inc. VAT
GVM-1101
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
LevelOne GVM-1101 — Managed Gigabit Media Converter, RJ45 to SC Multi-Mode Fiber, 500 m
10/100/1000 RJ45 ↔ 1000Base-XSC multi-mode · 850 nmUp to 500 mWeb · SNMP · OAM
The LevelOne GVM-1101 is a managed Gigabit Ethernet media converter that links a 10/100/1000Base-T copper port to 1000Base-X multi-mode fibre with an SC connector, for runs of up to 500 m at 850 nm. It suits building-to-building links, server-room uplinks and campus backbones where you want Gigabit over existing multi-mode fibre and also want to see and control what the link is doing.
Unlike a plain converter, the GVM-1101 can be configured through a web interface and monitored over SNMP. It supports IEEE 802.3ah OAM (link discovery, MIB variable response, remote loopback and dying-gasp alarm), Q-in-Q VLAN tagging, per-port speed/duplex/flow-control settings for the local and remote unit, bandwidth limiting in 64 kbps steps and jumbo frames up to 9 KB. Power comes from a built-in supply through a mains cord.
Before you order: This model has an SC connector and works on multi-mode fibre at 850 nm, up to 500 m. The far end must be 1000Base-SX-compatible multi-mode — another GVM-1101 or a switch port/SFP of the same type. It will not link to single-mode fibre (1310/1550 nm), to 100 Mbps fibre ports, or to LC/ST ports without the matching multi-mode patch cord.
What's in the Box
- 1 × LevelOne GVM-1101 managed media converter
- 1 × power cord (built-in power supply)
- 1 × Quick Installation Guide
- 1 × Declaration of Conformity
- Fibre patch cords are not included
What It Means in Practice
- A pair of GVM-1101 units turns two copper Gigabit ports into a 500 m multi-mode fibre link that you can manage from either end.
- OAM loopback lets you test the fibre path remotely, and the dying-gasp alarm tells you when the far unit has lost power — useful when the other end is in a locked room or another building.
- SNMP and web access mean the link can be watched from your existing monitoring tool rather than treated as an invisible box in the cable path.
- Bandwidth limiting lets you cap a tenant or a camera network on the same fibre without a separate router.
- With LFP, a fibre fault is reflected on the copper port so the switch on each end reacts to the outage.
What Will Not Work
- It will not work over single-mode fibre — for single-mode links look at single-mode models such as the LevelOne FVM-1220 (Fast Ethernet, 20 km).
- It will not reach beyond 500 m on multi-mode fibre.
- It has no SFP slot; the fibre interface is a fixed SC multi-mode port.
- It does not supply PoE on the RJ45 port.
- It is not a switch: one copper port and one fibre port only.
Key Features
Gigabit over fibre
10/100/1000Base-T copper to 1000Base-X multi-mode SC fibre, up to 500 m at 850 nm.
Full management
Web interface and SNMP (MIB files provided) with local and remote port configuration.
802.3ah OAM
Discovery, MIB variable response, remote loopback and dying-gasp alarm for remote diagnostics.
VLAN and bandwidth control
Q-in-Q dual tagging, bandwidth limits in 64 kbps steps, jumbo frames to 9 KB, LFP.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
Choose the GVM-1101 when a Gigabit fibre link matters enough that you want to monitor it and test it remotely. If your core already has a switch with an SFP slot, a 1000Base-SX SFP module may be simpler; the GVM-1101 earns its place where the far end is copper-only or you need OAM diagnostics on the link itself.
✓ Buy it if you need managed Gigabit over multi-mode fibre up to 500 m, with SNMP, VLAN and remote loopback.
✕ Skip it if your fibre is single-mode, the run is longer than 500 m, or a simple unmanaged converter is enough.
→ Also consider LevelOne FVM-1220 (managed Fast Ethernet, single-mode SC, 20 km) or FVT-2002 (unmanaged, multi-mode ST, 2 km).
Send us your fibre type and length plus the switch models at both ends and we will confirm the right converter or SFP before you order.
Features - LevelOne - GVM-1101
More Details
Product Code
04:245495
EAN Code
4015867195673
Manufacturer
LevelOne
