LevelOne SFP-2506 2.5 Gbps Single-Mode SFP Transceiver 1550 nm Duplex LC up to 80 km DDM MSA-Compliant
Brand:
LevelOne
LevelOne SFP-2506 2.5 Gbps Single-Mode SFP Transceiver 1550 nm Duplex LC up to 80 km DDM MSA-Compliant
€121.67 inc. VAT
SFP-2506
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
LevelOne SFP-2506 — 2.5G Single-Mode SFP, 80 km
2.5 Gbps1550 nm · LCUp to 80 kmDDM
The LevelOne SFP-2506 is a 2.5 Gbps single-mode SFP transceiver that carries 2.5 Gigabit Ethernet over 9/125 µm fibre up to 80 km at 1550 nm, through a duplex LC connection with digital diagnostics. It is the commercial-temperature version (0 to +70 °C) for long metro links, regional backhaul and ISP distribution fed from an indoor rack. In practice, single-mode optics are the choice when a link leaves the building or runs several hundred metres: the OS2 fibre used by carriers and campus backbones carries the signal for kilometres with little loss. Before you order, confirm the fibre is single-mode at both ends and note the length and the number of patch panels on the way.
Compatibility — check before buying:
This is a 2.5G optic: the port must support 2.5G SFP optics — many SFP ports run only 1G and many SFP+ ports only 10G, and LevelOne publishes no 1G or 10G mode. The far end must be a matching 2.5G, 1550 nm module. For outdoor cabinets choose the industrial SFP-2606 (−40 to +85 °C) instead; this SFP-2506 is rated 0 to +70 °C. On short runs a long-reach 1550 nm optic can overload the receiver — tell us the distance. Keep the dust cap on until you connect the fibre, and clean both connector ends before every mating — dirt is the most common cause of a link that will not come up. Not sure? Send us your device model and the cable run and we check it before you order.
Best For
✓ 2.5G metro links up to 80 km
✓ Regional telco backhaul
✓ ISP distribution networks
✓ Indoor racks at both ends
✓ 2.5G-capable SFP ports
✓ Replacing a failed SFP-2506
Key Features
2.5G over 80 km
The longest-reach 2.5G module in LevelOne’s SFP-25xx series, at 1550 nm over single-mode fibre.
Single-mode fibre, long reach
Built for single-mode (OS1/OS2) fibre, the type used between buildings, floors and sites. It will not run over the orange or aqua multimode fibre found in many racks — the fibre type has to match at both ends.
Monitoring you can read
Digital diagnostics (DDM/DOM) let the host report temperature, laser power and received light, so a dirty connector or a failing link shows up before users call.
Hot-swappable
Modules and cables plug into a live port without shutting the switch down, so a link can be added or replaced during working hours. Seat it until it clicks and use the latch or pull tab to remove it.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
We offer the SFP-2506 for 2.5G links that leave the building by tens of kilometres, on switches and converters whose SFP ports accept 2.5G optics. Order both ends together and confirm the fibre length and loss with your provider. If either end sits in an outdoor cabinet, the SFP-2606 is the right choice. Every order is backed by Singular’s local support in Cyprus — if a link will not come up, send us the port status and we help you find out whether it is the module, the cable or the configuration. Browse all transceivers and DAC cables or the switches they plug into.
Buyer’s Guide
Buy it if
You need 2.5G over single-mode fibre up to 80 km on ports that accept 2.5G SFP optics, in indoor racks.
Skip it if
Your ports run only 1G or 10G, the run is short, or an end sits in an outdoor cabinet (SFP-2606).
Also consider
LevelOne SFP-2606 for industrial temperatures.
Features - LevelOne - SFP-2506
More Details
Product Code
04:520239
EAN Code
4015867240045
Manufacturer
LevelOne
