Lexmark 40X7774 ADF Pick Roller — replacement feed roller for the XM5200 / XM7200 MFP document feeder
Genuine LexmarkADF partSingle rollerXM5200 / XM7200
The Lexmark 40X7774 is the genuine ADF pick roller for the automatic document feeder of the Lexmark XM5263, XM5270, XM7263 and XM7270 mono laser multifunction printers.
The pick roller pulls the top sheet from the ADF input tray into the scanner. When its rubber hardens or wears, originals stop feeding, feed at an angle or jam at the entry of the document feeder, while copying from the flatbed glass keeps working normally.
Before you order: 40X7774 is the pick roller only — a single part. Lexmark also offers a complete ADF Maintenance Kit (40X8431) that contains a pick roller, separation roller and feed belt; choose the kit if the separation parts are also worn.
What's in the Box
- 1 x Lexmark ADF pick roller (40X7774)
What It Means in Practice
- A worn pick roller typically causes "nothing feeds" or skewed scans from the ADF, while flatbed scanning still works.
- If the ADF also pulls several sheets at once, the separation roller is likely worn too — consider the full ADF maintenance kit.
- Clean the ADF rollers before replacing them; dirty rubber can cause the same symptoms.
- Lexmark publishes a "Replacing the ADF pick roller" procedure in the printer user guide.
What Will Not Work
- It does not fix paper-tray feeding problems in the printer engine.
- It does not replace the ADF separation roller or feed belt.
- It does not fit the MX720/MX820 or CX820/CX860 series, which use the 41X0358 roller.
- It will not fix lines in copies, which come from dirty scanner glass.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
On busy XM5200 and XM7200 MFPs the ADF does a lot of scanning work, and the pick roller is usually the first part to wear. A single roller is the low-cost fix when originals stop feeding. Browse our printer accessories and service parts for other Lexmark parts.
✓ Buy it if originals no longer feed reliably through the ADF of your XM5263, XM5270, XM7263 or XM7270.
✕ Skip it if the ADF also pulls several sheets at once — order the complete ADF maintenance kit instead.
→ Also consider Lexmark 40X8431 ADF Maintenance Kit for a full ADF roller refresh.
Not sure which part your Lexmark needs? Send us the model and serial from the printer label and we will check it before you order.
Features - Lexmark - 40X7774
More Details
Product Code
03:203572
EAN Code
0734646497893
Manufacturer
Lexmark
