LogiLink NP0123 Cat.6A Wall Outlet Flush Mount 2x RJ45 Shielded 500 MHz 10GbE PoE++ LSA Horizontal Cable Entry Signal White
Brand:
LogiLink
LogiLink NP0123 Cat.6A Wall Outlet Flush Mount 2x RJ45 Shielded 500 MHz 10GbE PoE++ LSA Horizontal Cable Entry Signal White
€11.5 inc. VAT
NP0123
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Cat.6A Wall Outlet — 2× RJ45, shielded, flush mount
Cat.6A 500 MHz10 Gigabit2× RJ45 shieldedSignal white
The LogiLink NP0123 is a shielded Cat.6A wall outlet with two RJ45 ports, made for flush mounting in the wall or in a cable duct. It is specified up to 500 MHz for 10 Gigabit Ethernet, carries PoE, PoE+ and PoE++, and terminates on LSA strips for 22–24 AWG installation cable. The two sockets sit at 40° so the patch cables hang down neatly, and the die-cast zinc housing with a combined shield contact keeps the shielding continuous. The face is signal white (RAL 9003) with horizontal cable entry. In practice it is the finishing point of a 10G-ready installation for desks, access points and cameras.
Compatibility — check before buying:
No back box in the box. It fits a flush wall box or a cable duct; for surface mounting on a bare wall you need LogiLink NP0223 (surface box) — or choose NP0124, which comes with one. LogiLink does not publish the required flush-box depth. Termination is on LSA strips with a punch-down (LSA) tool; the tool and the installation cable are not included. Colour: signal white RAL 9003 — it will not match pure-white (RAL 9010) fittings exactly. Not sure which outlet suits your wall box or cable? Tell us the cable type and a photo of the wall point, and we check it for you.
Best For
✓ Offices and home offices
✓ Wall points for PCs and printers
✓ Access points and IP cameras (PoE)
✓ VoIP phones at the desk
✓ New structured cabling
✓ Replacing old or damaged outlets
Key Features
10G-ready Cat.6A
Up to 500 MHz for 10 Gigabit Ethernet over shielded installation cable.
Two angled ports
Two shielded RJ45 at 40°, so cables hang down and do not stick out.
Full shielding
Die-cast zinc housing with combined shield contact.
PoE up to PoE++
Carries PoE, PoE+ and PoE++ to access points, cameras and phones.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
For new 10G cabling we recommend fitting Cat.6A outlets like the NP0123 even if today’s devices are Gigabit: the wall point then will not be the bottleneck later. Check the white tone of your switch range first — signal white and pure white look different side by side. For the active side, see our switches and access points. Singular’s direct warranty is 1 year, and we support you locally for anything beyond it.
Buyer’s Guide
Buy it if
You need a shielded 10G wall point for a flush box or duct.
Skip it if
You need to mount on a bare wall without a box.
Also consider
LogiLink NP0124 — Cat.6A outlet with surface box, pure white.
Features - LogiLink - NP0123
Colour
white
More Details
Product Code
04:164854
EAN Code
4052792028645
Manufacturer
LogiLink
