Description
This AD0019 is an economical choice to convert M.2 SSD into a 2,5'' (6,35cm) SATA SSD storage device. Once being installed into PC/laptop, the M.2 SSD appears as an ordinary SATA storage to any OS and can be configured as a bootable device.
LogiLink / Storage enclosure | AD0019
Special Features
- Converts a M.2 SATA III SSD to be a 2,5" (6,35cm) SATA SSD
- Can be a primary bootable device containing the OS (depends on the M.2 SSD and motherboard BIOS)
- No driver installation required
- Can be embedded storage in PC/notebook or as an external 2.5" SSD with SATA adapter
- Compatible with B+M Key M.2 NGFF (SATA) SSD 2230/2242/2260/2280mm
- SATA Interface: 22 pin
- Support Windows and MAC OS
Product Specification
| Device Type | Storage enclosure - external |
| Hard Drive Form Factor Compatibility | M.2 |
| Host Bus | SATA 6Gb/s |
| Interface | M.2 Card |
| Supported Devices | Solid state drive |
| Max Storage Devices Qty | 1 |
| Bays | 1 x internal - M.2 NGFF 2230/2242/2260/2280 |
| Interfaces | 1 x M.2 Card - NGFF B + M key (internal) |
| Connections | 1 x SATA 6Gb/s - 22 pin Serial ATA |
| Included Accessories | Screwdriver, screws |
| Compliant Standards | Plug and Play, EN 50581:2012, RoHS 2011/65/EU, EN 61000-3-3:2013, EMC 2014/30/EU, EN 61000-3-2:2014, EN 55032:2012, EN 55035:2017 |
| OS Required | Apple MacOS, Microsoft Windows |
| Width | 7 cm |
| Depth | 10.038 cm |
| Height | 0.7 cm |
| Weight | 40 g |
| Shipping Width | 9 cm |
| Shipping Depth | 13.3 cm |
| Shipping Height | 2 cm |
| Shipping Weight | 75.3 g |
Features - LogiLink - AD0019
More Details
Product Code
04:366336
EAN Code
4052792048704
Manufacturer
LogiLink
