PLANET PWR-480-48 Industrial DIN Rail Power Supply 480W 48V DC 10A MEAN WELL XDR-480E-48 85-264V AC Input -40 to 70C

Brand:
Planet
PLANET PWR-480-48 480W 48V DIN Rail Power Supply
PLANET PWR-480-48 Industrial DIN Rail Power Supply 480W 48V DC 10A MEAN WELL XDR-480E-48 85-264V AC Input -40 to 70C
€249.95 inc. VAT
Buy
PWR-480-48
€210.04
€249.95 inc. VAT
Ships from EU stock: 1 item(s)
+ −
Add to wish list Ask a question
Product Code
04:221648
EAN Code
4016032385790
Manufacturer
Planet

Quick Specs

Output
48 V DC, 10 A, 480 W
Input
85–264 V AC / 127–370 V DC
Mounting
DIN rail TS-35/7.5 or 15
Temperature
−40 to 70 °C (derating)
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

PLANET PWR-480-48 — 480 W, 48 V DIN rail

480 W48 V DCDIN rail−40 to 70 °C

The PLANET PWR-480-48 is a 480 W, 48 V DC single-output industrial DIN-rail power supply. PLANET lists it as based on the MEAN WELL XDR-480E-48, and builds the range to feed industrial Ethernet equipment — typically PLANET industrial PoE switches — in control cabinets. It delivers 48 V at 10 A from a wide 85–264 V AC (50/60 Hz) or 127–370 V DC input, clips onto a TS-35/7.5 or TS-35/15 rail, and is cooled by free-air convection. Protection covers short circuit, overload, over-voltage and over-temperature. PLANET publishes 48 × 125 × 125 mm and 890 g for hardware version 3.

Compatibility — check before buying:
Check the DC input of the device you will power. Many PoE switches need 51–56 V at their DC input to deliver full 802.3at/bt power, so a 48 V nominal supply may limit the PoE output — confirm the switch’s requirement first. PLANET’s figures apply to hardware version 3; earlier versions used different MEAN WELL units. Full output up to 70 °C follows the derating curve in the product specification. This is an open-terminal supply for installation in a cabinet by a qualified person. Not sure? Tell us your model and we check it for you.

Best For

✓ PLANET industrial PoE switches
✓ Control cabinets
✓ Factory and utility sites
✓ Outdoor enclosures with heating/cooling
✓ 48 V industrial equipment
✓ Replacing a failed DIN-rail PSU

Key Features


480 W at 48 V
10 A continuous output.

Wide input
85–264 V AC or 127–370 V DC.

−40 to 70 °C
Free-air convection cooling.

Full protection
Short circuit, overload, over-voltage, over-temperature.

Technical Specifications

Identification
Brand PLANET
Product PWR-480-48 – 480W 48V DC Single Output Industrial DIN-rail Power Supply (MEAN WELL XDR-480E-48)
Part Number PWR-480-48
EAN / GTIN 4016032385790
Model PLANET PWR-480-48
Base unit MEAN WELL XDR-480E-48 (as listed by PLANET)
Product Type Industrial DIN-rail power supply
Output
Voltage 48 V DC
Current 10 A
Power 480 W
Input
AC 85–264 V AC, 50/60 Hz
DC 127–370 V DC
Protection & Cooling
Protection Short circuit, overload, over-voltage, over-temperature
Cooling Free-air convection
Physical & Environment
Dimensions (W × H × D) 48 × 125 × 125 mm (HW v3)
Weight 890 g (HW v3)
Mounting DIN rail TS-35/7.5 or 15
Operating temperature −40 to 70 °C (see derating curve)
Storage temperature −40 to 85 °C
Humidity 20–95% operating, 10–95% storage, non-condensing
Safety & Approvals
Standards UL 61010; EN 62368-1; EN 61558-1/-2-16; CB IEC 62368-1, IEC 61558-1; TUV EN 61010
Other marks RCM, BSMI, CCC, EAC, KC, BIS
Before You Order
Your device Accepts 48 V DC; check PoE input needs
Rail TS-35 DIN rail
Hardware version Specs published for v3
In the Box
Included Power supply unit (PLANET does not publish further box contents)
Not Included DIN rail; mains and DC wiring; enclosure
Warranty
Warranty 1-Year Warranty (Singular)
Manufacturer Term PLANET does not publish a warranty term for this item on its product page or datasheet. Singular’s direct warranty is 1 year, and we support you locally for anything beyond it.

Frequently Asked Questions

Is it made by MEAN WELL?
PLANET lists the MEAN WELL XDR-480E-48 as the base unit.
Can it power a PoE switch?
Yes, if the switch accepts 48 V DC; many need 51–56 V for full PoE, so check first.
Does it accept DC input?
Yes, 127–370 V DC.
Which rail does it fit?
TS-35/7.5 or TS-35/15.
Singular Expert Insight
Size the supply with margin: a 480 W unit comfortably feeds a switch with a 360–400 W PoE budget. Leave space above and below for convection. For industrial switches, see our switches.

Buyer’s Guide

Buy it if

You need 480 W at 48 V DC on a DIN rail for industrial network equipment.

Skip it if

Your switch needs 54 V DC or more at its input.

Also consider

PLANET PWR-240-48 or PWR-960-48 for other power levels.
