MERCUSYS MS105GS 5-Port Gigabit Desktop Switch, Steel

Brand:
MERCUSYS
MERCUSYS MS105GS switch, front three-quarter view
MERCUSYS MS105GS 5-Port Gigabit Desktop Switch, Steel
€17.33 inc. VAT
Buy
MS105GS(UN)
€14.56 €16.18
€17.33 inc. VAT
Ships from EU stock: 10 item(s)
+ −
Add to wish list Ask a question
Product Code
04:495628
EAN Code
6957939001315
Manufacturer
MERCUSYS
Quick Specs
Ports
5 × 10/100/1000 Mbps RJ45
Capacity
10 Gbps aggregate switching
Management
Unmanaged, plug-and-play
Installation
Desktop or wall mount
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

MERCUSYS MS105GS 5-Port Gigabit Switch

5 × 10/100/1000 Mbps RJ4510 Gbps aggregate switchingUnmanaged, plug-and-playDesktop or wall mount

The MERCUSYS MS105GS is an unmanaged five-port Gigabit desktop switch in a black steel enclosure. It adds wired network connections to an existing router or switch; it does not provide routing, Wi-Fi or a modem. The shipped hardware revision is not specified.

Best For: Suitable for a home or small office that needs additional wired Gigabit ports and already has a router or switch. If using a router uplink, four ports remain for client devices.
Before you order: The 10 Gbps figure is aggregate switching capacity, not the speed of one port or an Internet connection. Every port supports up to 1 Gbps. An uplink occupies one port; Ethernet cables are separate. The shipped revision is unknown, so revision-dependent IGMP Snooping and 802.1p/DSCP QoS are not claimed.

What's in the Box

  • MERCUSYS MS105GS five-port Gigabit switch
  • External 5 V, 0.6 A DC power adapter
  • Quick Installation Guide

What It Means in Practice

  • Connect an Ethernet uplink from an existing router or switch to one of the five ports; this leaves four ports for client devices.
  • For Gigabit links, use four-pair Cat 5e-or-better UTP/STP cable; the manufacturer specifies a maximum cable length of 100 m.
  • The switch is unmanaged and requires no configuration interface. Link speed and actual transfer depend on the connected devices, cable and network.
  • It can be placed on a desktop or wall-mounted indoors. Green Ethernet adjusts consumption by link status and cable length, but no specific saving is guaranteed.

What Will Not Work

  • No dedicated WAN/uplink port; the uplink uses one of the five ports.
  • No routing, modem, Wi-Fi or PoE power for endpoint devices. Cameras and access points need their own power or a separate injector, as applicable.
  • Ethernet cables, wall screws/anchors, security lock and endpoint devices are not listed as supplied; regional mains plug details for the adapter are not verified.
  • Indoor use only; it is not specified as weatherproof or industrial-rated.
  • The shipped V1/V2 hardware revision is unknown; revision-dependent IGMP Snooping and 802.1p/DSCP QoS are not confirmed.

Key Features


Five Gigabit ports
Connect wired devices at negotiated link speeds up to 1 Gbps per port.

Unmanaged operation
Plug-and-play use without a configuration interface.

Fanless steel case
A compact metal enclosure with no fan, for desktop or wall installation.

Green Ethernet
Adjusts power consumption to link status and cable length; savings are not quantified.

Technical Specifications

Ports5 × 10/100/1000 Mbps auto-negotiation RJ45; Auto MDI/MDIX
Port rolesNo dedicated WAN/uplink port; an uplink uses one of the five ports
Switching capacity10 Gbps aggregate switching capacity; not single-port speed or Internet speed
MAC address table2K; auto-learning and auto-aging
Forwarding and flow controlStore-and-forward; IEEE 802.3x flow control
Network standardsIEEE 802.3, 802.3i, 802.3u, 802.3ab, 802.3x, 802.3p
Gigabit cabling1000BASE-T requires 4-pair Cat 5e-or-better UTP/STP; manufacturer specifies ≤100 m
Other cable media10BASE-T: 2-pair Cat 3-or-better UTP/STP, ≤100 m; 100BASE-TX: 2-pair Cat 5-or-better UTP/STP, ≤100 m
ManagementUnmanaged; plug-and-play, with no configuration interface required
Enclosure and installationBlack steel/metal case; fanless; desktop or wall-mount installation
Dimensions99.8 × 98 × 25.1 mm
Power supplyExternal 5 V, 0.6 A DC adapter supplied
Maximum power consumption3.614 W maximum; not a constant consumption figure
Power over EthernetDoes not supply PoE power to endpoint devices
Green EthernetAdjusts power consumption according to link status and cable length; no percentage saving specified
Operating environment0–40°C; 10–90% RH, non-condensing
Storage environment−40–70°C; 5–95% RH, non-condensing
Installation environmentIndoor desktop or wall installation; not a weatherproof industrial switch
IndicatorsPower and Link/Act LEDs
Manufacturer SKUMS105GS(UN)
EAN6957939001315

Frequently Asked Questions

Does it provide 10 Gbps on one port?
No. The 10 Gbps figure is aggregate switching capacity. Each of the five ports supports up to 1 Gbps.
How many client ports remain when connected to a router?
Four, when the router uplink uses one of the five ports. There is no dedicated uplink port.
Are Ethernet cables included?
Ethernet cables are not listed as supplied. The power adapter and Quick Installation Guide are listed in the package contents.
Does it power cameras or access points?
No PoE power is supplied to endpoint devices. They need their own power or a separate injector, as applicable.
Singular Expert Insight

It combines five auto-negotiating Gigabit ports, unmanaged plug-and-play operation and a fanless steel enclosure in a compact desktop or wall-mountable switch.

Buyer’s Guide

✓ Buy it if Suitable for a home or small office that needs additional wired Gigabit ports and already has a router or switch. If using a router uplink, four ports remain for client devices.
✕ Skip it if The 10 Gbps figure is aggregate switching capacity, not the speed of one port or an Internet connection. Every port supports up to 1 Gbps. An uplink occupies one port; Ethernet cables are separate. The shipped revision is unknown, so revision-dependent IGMP Snooping and 802.1p/DSCP QoS are not claimed.
