ASUS PRIME H810M-E-CSM Motherboard micro-ATX LGA1851 H810 DDR5 PCIe 4.0 M.2 HDMI DisplayPort

Brand:
ASUS
ASUS PRIME H810MECSM Motherboard micro ATX 90MB1N20M0EAYC
ASUS PRIME H810M-E-CSM Motherboard micro-ATX LGA1851 H810 DDR5 PCIe 4.0 M.2 HDMI DisplayPort
€151.39 inc. VAT
Buy
90MB1N20-M0EAYC
€127.22 €141.36
€151.39 inc. VAT
Ships from EU stock: 10 item(s)
+ −
Add to wish list Ask a question
Product Code
04:575180
EAN Code
4711636188203
Manufacturer
ASUS

Quick Specs

Socket
Intel LGA1851
Chipset
Intel H810
CPU Support
Core Ultra Series 2
Memory
2 x DDR5, up to 7200MT/s
Storage
2 x M.2 PCIe 4.0 + 4 x SATA
Video Out
2 x DP + 1 x HDMI 2.1
LAN
1Gb Ethernet
CSM Support
36-month lifecycle
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Singular Selected

ASUS PRIME H810M-E-CSM

Commercial-grade micro-ATX motherboard for Intel Core Ultra Series 2 — built for office fleets and IT deployments with 36-month lifecycle support and ASUS Control Center Express included.
LGA1851 · Core Ultra Series 2DDR5 up to 7200MT/s2 x M.2 PCIe 4.0CSM Lifecycle

The ASUS PRIME H810M-E-CSM is a commercial micro-ATX motherboard built for Intel’s new Core Ultra Series 2 desktop processors on the LGA1851 socket. As part of the ASUS Corporate Stable Model program, it ships with up to 36 months of product lifecycle support, 6-month end-of-life notice, and ASUS Control Center Express — server-grade IT management software for remote BIOS updates, asset tracking and fleet monitoring. The board pairs a 6+1+1+1 discrete MOSFET power design with two DDR5 DIMM slots that scale to 7200MT/s on Core Ultra 200S Plus CPUs and 6400MT/s on standard 200S, two M.2 slots (one PCIe 4.0 x4, one PCIe 4.0 x2), four SATA III ports, dual DisplayPort plus HDMI 2.1 outputs, and a Realtek 1Gb LAN. It is the right pick for businesses, system integrators and SMB workstations that prioritise stability and supply continuity over enthusiast features like Wi-Fi or 2.5G LAN.

Compatibility Note: LGA1851 socket only — works exclusively with Intel Core Ultra Series 2 desktop processors. Not compatible with 12th/13th/14th Gen Intel CPUs (those use LGA1700). DDR5 memory only (DDR4 modules will not fit). HDMI/DisplayPort output requires a CPU with integrated graphics. No onboard Wi-Fi or 2.5G LAN. Please confirm CPU and case (micro-ATX) compatibility before purchase.
Best For
✓ Business & office workstations
✓ SMB & enterprise IT fleets
✓ System integrators
✓ AI PC ready commercial builds
✓ Multi-monitor productivity setups
✓ Compact micro-ATX cases

Key Features


CSM Lifecycle Support
Up to 36 months of product lifecycle support and 6-month end-of-life notice — predictable supply for IT departments planning multi-year rollouts.

ASUS Control Center Express
Server-grade IT management software included free — remote BIOS updates, real-time monitoring, asset tracking and fleet deployment from a single console.

DDR5 + Dual M.2
2 DIMM slots up to 128GB DDR5 7200MT/s with XMP and AEMP II, plus two M.2 slots (PCIe 4.0 x4 + PCIe 4.0 x2) for primary OS and secondary storage.

Triple Display Output
Two DisplayPort 1.4 (4K@60Hz) plus HDMI 2.1 (4K@60Hz) outputs — drive three independent displays from the iGPU without a discrete graphics card.

Technical Specifications

Part Number 90MB1N20-M0EAYC
EAN 4711636188203
Form Factor micro-ATX
Socket Intel LGA1851 — Core Ultra Series 2 only
Chipset Intel H810
Power Phase 6+1+1+1 Discrete MOSFET
Memory 2 x DIMM, max 128GB, DDR5 up to 7200MT/s (Core Ultra 200S Plus) / 6400MT/s (200S), Dual Channel, Non-ECC, CUDIMM, XMP, AEMP II
Expansion Slots 1 x PCIe 4.0 x16 (CPU) + 1 x PCIe 4.0 x1 (chipset)
Storage M.2_1 type 2280 (PCIe 4.0 x4) + M.2_2 type 2242/2260/2280 (PCIe 4.0 x2) + 4 x SATA III 6Gb/s
Graphics Output 2 x DisplayPort 1.4 (4K@60Hz) + 1 x HDMI 2.1 (4K@60Hz) — requires CPU with iGPU
LAN Realtek 1Gb Ethernet
Wireless Not included — for Wi-Fi see PRIME H810M-A WIFI-CSM
Audio Realtek 7.1 HD Audio Codec, 24-bit/192 kHz playback
USB Rear: USB 3.2 Gen 1 Type-A + USB 2.0 Type-A; Front headers: USB 3.2 Gen 1 Type-C, USB 3.2 Gen 1, USB 2.0
CSM Program Up to 36-month lifecycle, 6-month EOL notice, ASUS Control Center Express included
Cooling VRM heatsink, PCH heatsink, hybrid fan headers, Fan Xpert 2+
DIY Features SafeSlot Core+, Q-DIMM, Q-LED Core, Q-Slot
In the Box Motherboard, SATA cables, I/O shield, M.2 anchor, user manual (verify with retailer for exact bundle)

Frequently Asked Questions

What is the CSM program and why does it matter for businesses?
ASUS Corporate Stable Model is a commercial program that guarantees up to 36 months of product lifecycle support and 6-month end-of-life notice for IT planning. Each CSM purchase includes ASUS Control Center Express — server-grade IT management software for remote BIOS updates, asset tracking and fleet deployment.
Will my 13th or 14th Gen Intel CPU work in this board?
No. The H810M-E-CSM uses the new LGA1851 socket designed exclusively for Intel Core Ultra Series 2 desktop processors. 12th, 13th and 14th Gen Intel CPUs use the older LGA1700 socket and are physically incompatible.
Does this motherboard include Wi-Fi or 2.5G LAN?
No. This is the H810M-E-CSM with 1Gb Ethernet only and no onboard Wi-Fi. For Wi-Fi 6 with the same chipset and CSM program, look at the PRIME H810M-A WIFI-CSM. For 2.5G LAN you need to step up to a B860 board.
How many displays can I drive without a graphics card?
Up to three independent displays via the two DisplayPort 1.4 ports plus the HDMI 2.1 port — provided the installed Core Ultra CPU has integrated graphics. Maximum supported resolution is 4K@60Hz on each output.
Singular Expert Insight
Choose the H810M-E-CSM if you are deploying Intel Core Ultra Series 2 systems for business use and need predictable supply, IT management tools and triple-display productivity output. If you need Wi-Fi 6 onboard, step up to the PRIME H810M-A WIFI-CSM. For consumer/home builds without commercial features, the standard H810 boards or B860 series offer better value (2.5G LAN, more M.2 slots, Wi-Fi 6E). If you already own LGA1700 hardware, this board will not work with it — pick a B760 or H610 board instead.

Buyer's Guide

Buy it if
You are deploying business workstations on Intel Core Ultra Series 2 and need 36-month lifecycle support, IT management tools and triple-display productivity output.
Skip it if
You own a 12/13/14th Gen Intel CPU (incompatible LGA1700), need onboard Wi-Fi or 2.5G LAN, want PCIe Gen5 M.2, or you are building a gaming/enthusiast system.
Also consider
PRIME H810M-A WIFI-CSM for Wi-Fi 6 + dual M.2 PCIe 4.0, ASRock B860M-X WiFi for consumer 2.5G LAN + Wi-Fi 6E, or a B860 CSM for stronger VRM with commercial features.
