Microchip PD-9501GCS / Media converter / GigE / 1000Base-X / RJ-45 / SFP (mini-GBIC) | PD-9501GCS/AC-EU
Please sign in so that we can notify you about a reply
Special Features
- Media converter - SFP to PoE
- IEEE 802.bt type 3 compliant
- IEEE 802.3af/at backward compatible
- All 3 ports can be active simultaneously
- Output power of 60W over 4-pairs is guaranteed
- Supports 10/100/1000Base-T
- Safe: low-power devices receive only the power they need
Product Specification
| Device Type | Media converter |
| Form Factor | External |
| Localisation | Europe |
| Networking | Networking |
| Connectivity Technology | Wired |
| Cabling Type | 1000Base-X |
| Data Link Protocol | 10Mb LAN, 100Mb LAN, GigE |
| Data Transfer Rate | 1 Gbps |
| Status Indicators | Status |
| Features | 60W PoE power budget |
| Compliant Standards | IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt Type 3 |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x Ethernet 1000Base-X - SFP ¦ 1 x Ethernet 1000 - RJ-45 ¦ 1 x Ethernet 1000 (PoE output) - RJ-45 |
| Miscellaneous | Miscellaneous |
| MTBF | 150,000 hours |
| Compliant Standards | VCCI, EN55024, FCC Part 15 B, RoHS, WEEE, EN 55032 Class B, IEC/EN/UL 60950-1 |
| Power | Power |
| Power Over Ethernet (PoE) | PoE++ |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 8 cm |
| Depth | 16 cm |
| Height | 3.6 cm |
| Weight | 400 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 1 year |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -10 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 95% (non-condensing) |
Features - Microchip - PD-9501GCS/AC-EU
More Details
Product Code
CC04098
EAN Code
0844117002898
Manufacturer
Microchip
