Lenovo ThinkPad USB4 Smart Dock 5500, 40Gbps, 65W Laptop Charging, 100W EU Adapter, Gigabit LAN, Eclipse Black

Brand:
Lenovo
Lenovo ThinkPad USB4 Smart Dock 5500, Eclipse Black
Lenovo ThinkPad USB4 Smart Dock 5500, 40Gbps, 65W Laptop Charging, 100W EU Adapter, Gigabit LAN, Eclipse Black
€237.38 inc. VAT
Buy
40BC0100EU
€199.48
€237.38 inc. VAT
Ships from EU stock: 93 item(s)
+ −
Add to wish list Ask a question
Product Code
03:282138
EAN Code
0195892120551
Manufacturer
Lenovo

Quick Specs

Host connection
USB4 / up to 40Gbps
Laptop charging
Up to 65W / 100W adapter included
Displays
Up to 4 / host and OS dependent
Wired network
Gigabit Ethernet
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Lenovo ThinkPad USB4 Smart Dock 5500, 40Gbps, 65W Laptop Charging, 100W EU Adapter, Gigabit LAN, Eclipse Black

USB4 / up to 40GbpsUp to 65W / 100W adapter includedUp to 4 / host and OS dependent

This EU ThinkPad USB4 Smart Dock 5500 bundle brings desktop displays, USB peripherals and Gigabit Ethernet to a compatible laptop through its integrated 1m USB4 cable. The included 100W Slim Tip adapter supplies the dock; laptop charging is up to 65W in this configuration. Choose it for a desk setup whose charging needs fit that limit, and check the laptop’s video capabilities before planning multiple monitors.

Compatibility — check before buying:
Requires compatible host video/data/power capabilities; a USB-C connector alone is insufficient.

Key Features


Know the charging budget
A 100W adapter does not mean 100W reaches the laptop. This bundle supplies up to 65W; the separate 135W adapter configuration is required for Lenovo’s higher charging reference.

Choose displays around the host
HDMI, two DisplayPorts and full-function USB-C provide four video connections. Lenovo cites one 8K/60Hz, two 4K/144Hz or four 4K/60Hz displays on suitable configurations; macOS supports one extended external desktop through this MST dock.

Separate peripheral and network connections
Four 10Gbps USB-A ports and two downstream 10Gbps USB-C ports serve peripherals; the rear USB-C also carries video. Gigabit Ethernet gives a wired network connection. There is no audio jack.

Manage an office dock fleet
LAFM supports browser-based remote management, while Dock Manager handles supported Windows management tasks. ThinkPad power-button integration, MAC pass-through and Wake-on-LAN require a supported Lenovo host.

Technical Specifications

Identification and host connection
Brand / model Lenovo ThinkPad USB4 Smart Dock 5500
SKU / EAN 40BC0100EU / 0195892120551
Bundle / colour 100W power-adapter bundle, EU regional SKU; Eclipse Black
Upstream connection USB4, up to 40Gbps shared bandwidth, integrated 1m USB4 cable
Bandwidth reference 40Gbps is 4× the 10Gbps link rate of USB-C 3.2 Gen 2; interface comparison, not an application-speed guarantee
Host requirements Compatible USB-C / Thunderbolt host; display, charging and 40Gbps operation require corresponding host capabilities; verify exact system compatibility
Displays and peripheral ports
Video connectors 1 × HDMI 2.1, 2 × DisplayPort 1.4, 1 × full-function USB-C video port
Maximum display count Up to 4 external displays on a supported host configuration
Manufacturer display references One 8K at 60Hz, two 4K at 144Hz, or four 3840 × 2160 at 60Hz; alternative configurations, host/GPU/OS/display dependent
macOS display limitation Lenovo specifies one external extended desktop; multiple monitors use clone mode because macOS does not support MST extended desktops through this dock
Front USB-A 2 × USB-A 3.2 Gen 2 (10Gbps); one Always On USB, 12W
Front USB-C 1 × USB-C 3.2 Gen 2 (10Gbps), Always On USB, 7.5W
Rear USB-A 2 × USB-A 3.2 Gen 2 (10Gbps), 4.5W
Rear USB-C 1 × USB-C 3.2 Gen 2 (10Gbps), full-function video/data, 7.5W
Ethernet 1 × RJ-45 Gigabit Ethernet (1Gbps)
Audio ports None
Power and controls
Included power adapter 100W Slim Tip AC adapter, DC-IN / Slim-tip connector
Laptop charging with included adapter Up to 65W; laptop must support compatible USB-C power delivery
Optional higher-power configuration PD 3.1; Lenovo reference up to 100W for supported Lenovo hosts or 96W for other supported hosts requires 135W Slim Tip adapter, sold separately from this 100W bundle
Power button Dock power button; system-button emulation supported on compatible Lenovo ThinkPad notebooks, not Apple/other Windows systems in Lenovo matrix
MAC / Wake-on-LAN MAC address pass-through and Wake-on-LAN on supported Lenovo ThinkPad hosts; not universal across other platforms
Hardware security 1 × NanoSaver slot, 1 × MicroSaver slot; locks separate
Management and software
Cloud fleet management Lenovo Accessories Fleet Manager (LAFM), AWS-powered browser management, update/configuration/diagnostics; requires appropriate service/network setup
Local management Lenovo Dock Manager: firmware updates, device queries and analytics; supported Windows platforms; functions vary by host
Network identities USB Ethernet MAC for host LAN; separate IoT Wi-Fi MAC for management module, not a general-purpose Wi-Fi adapter claim
Listed operating systems Windows 11; macOS Sonoma, macOS Sequoia; functionality differs by OS
Drivers / firmware Drivers required; Lenovo USB LAN driver and Windows/macOS firmware tools available
Update support reference Lenovo lists dock and Dock Manager updates through 31 December 2033
Physical and operating details
Dimensions / weight 218 × 80 × 31.5mm / 472g
Package dimensions / weight 240 × 145 × 77mm / 1037g; brown box
Operating temperature 0°C to 40°C
Relative humidity 20% to 95%, non-condensing
Manufacturer term 3-year manufacturer warranty; Customer Replaceable Unit (CRU), subject to applicable Lenovo terms

What's in the Box

ThinkPad USB4 Smart Dock 5500 with integrated 1m USB4 cable
100W Slim Tip power adapter
Power cord for the regional bundle
Lenovo Accessories Fleet Manager flyer
Setup poster
Warranty poster

What Will Not Work

Requires compatible host video/data/power capabilities; a USB-C connector alone is insufficient.
Included 100W adapter supplies up to 65W laptop charging, not 100W.
macOS supports one external extended desktop; ThinkPad system-button, MAC pass-through and Wake-on-LAN integrations are host-specific.
No audio jack; locks and optional 135W adapter are separate.

Frequently Asked Questions

Why is laptop charging 65W when the adapter says 100W?
The adapter also powers the dock and attached devices. Lenovo lists 65W output with the 100W configuration. A compatible 135W Slim Tip adapter is required for the dock’s higher charging limits.
Can a Mac use four independent extended monitors?
No. Lenovo’s 40BC compatibility matrix specifies one external extended desktop on Apple notebooks; multiple connected monitors operate in clone mode. Check the exact Mac and display setup before ordering.
Will the dock button and corporate network functions work on any laptop?
No. Lenovo lists system power-button emulation, MAC address pass-through and Wake-on-LAN for supported ThinkPad hosts. Basic connectivity and charging support do not imply those integrations.
Singular Expert Insight
Match both the laptop’s charging requirement and display topology before choosing this 100W-adapter bundle. A laptop needing more than 65W or a Mac requiring several independent external desktops calls for a different verified configuration. Check your upgrade with Singular Tell us your equipment model and we can check the compatibility requirements.

Buyer’s Guide

Buy it if

You need USB4 peripherals and wired LAN on a compatible laptop whose dock charging needs fit 65W.

Skip it if

You require 100W laptop charging from this included adapter, an audio jack or multiple independent Mac desktops.

Also consider

The separately specified 135W-adapter dock bundle if your supported laptop needs higher charging power.
