Netgear AV Line M4250-26G4F-PoE++ GSM4230UP-100EUS Managed L3 Gigabit Ethernet Switch | 24-Port | 1440W PoE++

Brand: NetGear
NETGEAR AV Line M425026G4F-PoE++ Switch L3 GSM4230UP-100EUS
Netgear AV Line M4250-26G4F-PoE++ GSM4230UP-100EUS Managed L3 Gigabit Ethernet Switch | 24-Port | 1440W PoE++
€4362.89 inc. VAT
Buy
GSM4230UP-100EUS
€3,666.29 €4,073.66
€4,362.89 inc. VAT
Ships from EU stock: 7 item(s)
Built for AV racks, with 24 PoE++ ports, SFP uplinks and a 1U rack-mount design.
+ −
Add to wish list Ask a question
Product CodeCA81334 EAN Code0606449151701 ManufacturerNetGear

Quick Specs

  • Power: Internal power supply
  • Security: SSL 3.0 | TLS 1.0 | TLS 1.2 | AES
  • Interfaces: 24 x 10/100/1000 Base-T RJ-45 PoE++ - 90 W 2 x 10/100/1000 Base-T RJ-45 4 x 1000Base-X SFP 1 x management (Gigabit LAN) RJ-45 1 x management (RS-232) RJ-45 1 x USB-C 1 x USB Type A
  • Management Protocol: HTTP, Telnet, SSH, DHCP, CLI, RADIUS, ICMP, SNMP 1, SNMP 2, SNMP 3, RMON 1, RMON 2, RMON 3, RMON 9, TACACS+, SSH-2, TFTP, HTTPS, SCP, SFTP
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Netgear AV Line M4250-26G4F-PoE++ GSM4230UP-100EUS Managed L3 Gigabit Ethernet Switch
The Netgear AV Line M4250-26G4F-PoE++ is a managed L3 Gigabit Ethernet switch for rack-mounted AV environments. It combines 24 PoE++ copper ports, 4 SFP uplinks and a 1U side-to-side airflow chassis, with AV-focused integration features and front-panel status indicators.
Technical Specifications
Specification Detail
Product Type Switch - 24 ports - L3 - Managed
Ports 24 x 10/100/1000 Base-T RJ-45 PoE++ - 90 W | 2 x 10/100/1000 Base-T RJ-45 | 4 x 1000Base-X SFP | 1 x management (Gigabit LAN) RJ-45 | 1 x management (RS-232) RJ-45 | 1 x USB-C | 1 x USB Type A
Power over Ethernet PoE++
PoE Budget 1440 W
Enclosure Type Side to side airflow rack-mountable 1U
Switching Capacity 60 Gbps
Firewall Throughput 44.64 Mpps
Processor X ARM: 1.8 GHz
RAM 2 GB
Flash Memory 256 MB
MAC Address Table Size 16K entries
Jumbo Frame Support 12KB
Capacity ARP entries: 4000 | NDP entries: 4000 | Packet buffer size: 32 MB | VLANs supported: 4093 | IGMP multicast groups: 4000 | QoS hardware queues: 8 | IPv4 routes (static): 64 | IPv6 routes (static): 64 | RIP application route scaling (IPv4): 32 | IPv4 groups (Multicast): 512 | IPv6 groups (Multicast): 128
Routing Protocol IGMP | STP | MSTP | RSTP | IGMPv2 | IGMPv3 | MLD | MLDv2 | PIM-DM | PIM-DMv6 | PIM-SM | PIM-SMv6 | static IPv4 routing | static IPv6 routing | policy-based routing (PBR) | RIP-1 | RIP-2 | PIM-SSM
Remote Management Protocol HTTP | Telnet | SSH | DHCP | CLI | RADIUS | ICMP | SNMP 1 | SNMP 2 | SNMP 3 | RMON 1 | RMON 2 | RMON 3 | RMON 9 | TACACS+ | SSH-2 | TFTP | HTTPS | SCP | SFTP
Security SSL 3.0 | TLS 1.0 | TLS 1.2 | AES
Authentication Method Secure Shell (SSH) | RADIUS | TACACS+
Features LAG | PIM | DHCP server | PTP | AVB | IPTV support | sFlow | RSPAN | auto-sensing per device | LLDP support | dual firmware images | Energy Efficient Ethernet | store and forward | Voice VLAN | 802.1x authentication | TPID | GARP | GVRP | GMRP | MRP | MVRP | MVR | LACP support | full duplex mode | flow control | UDLD | RPVST+ | STP loop guard | STP Root Guard | STP BPDU Guard | STP BPDU Filtering | STP BPDU Flooding | IGMP snooping | MLD snooping | MGMD Snooping | IGMP proxy | MLD proxy | ASM | SSM | NDP | BOOTP support | DHCP relay | DNS client | ISDP | LLDP-MED | Broadcast Storm Control | Multicast Storm Control | Unicast Storm Control | DoS protection | MACAL | MAB | Port Security | IP source guard | DHCP snooping | DAI | RA guard | MAC address filtering | DiffServ support | QoS | CoS | WRED | SP | DSCP support | SNTP support | port mirroring | cable test
Compliant Standards IEEE 802.3af | IEEE 802.3at | IEEE 802.1ab (LLDP) | IEEE 802.3az | IEEE 802.1Q | IEEE 802.3ad (LACP) | IEEE 802.1AX | IEEE 802.1x | IEEE 802.3x | IEEE 802.1D | IEEE 802.1w | IEEE 802.1s | IEEE 802.1p | IEEE 802.1v | IEEE 802.3 | IEEE 802.3u | IEEE 802.3ab | IEEE 802.3ac | IEEE 802.3bt
Status Indicators Power | PoE max | fan | port status
Power Internal power supply
Installed Qty 2
Power Consumption Operational 1734 Watt
Power Consumption Stand by 36.9 Watt
Package Contents Rubber caps | rubber feet | Rubber caps, rubber feet
Cables Included 1 x console cable | 1 x USB-C to USB-A cable
Rack Mounting Kit Included
Localisation Europe
Width 44 cm
Depth 40 cm
Height 4.32 cm
Weight 6.746 kg
Service & Support Limited warranty - lifetime | Limited warranty - technical support - 90 days
Interfaces 24 x 10/100/1000 Base-T RJ-45 PoE++ - 90 W 2 x 10/100/1000 Base-T RJ-45 4 x 1000Base-X SFP 1 x management (Gigabit LAN) RJ-45 1 x management (RS-232) RJ-45 1 x USB-C 1 x USB Type A
Management Protocol HTTP, Telnet, SSH, DHCP, CLI, RADIUS, ICMP, SNMP 1, SNMP 2, SNMP 3, RMON 1, RMON 2, RMON 3, RMON 9, TACACS+, SSH-2, TFTP, HTTPS, SCP, SFTP
SKU / EAN GSM4230UP-100EUS | 0606449151701
SINGULAR RECOMMENDS
For who
For AV installers and network teams needing a managed rack switch with PoE++ ports, SFP uplinks and a clean 1U layout.
Real reason to buy it
It brings together 24 PoE++ gigabit ports, 4 SFP uplinks and a 1440W PoE budget in a rack-mount chassis built for AV integration.
Know before
This is a managed L3 switch for professional installations. The included warranty is lifetime, while technical support is limited to 90 days.
