NETGEAR GS524UP 24-Port Gigabit Unmanaged PoE++ Switch 16x 60W PoE++ 8x 30W PoE+ 480W Rackmount

Brand:
NetGear
NETGEAR GS524UP 24 port Switch unmanaged POE GS524UP-100EUS
NETGEAR GS524UP 24-Port Gigabit Unmanaged PoE++ Switch 16x 60W PoE++ 8x 30W PoE+ 480W Rackmount
€608.73 inc. VAT
Buy
GS524UP-100EUS
€511.54 €568.38
€608.73 inc. VAT
Ships from EU stock: 9 item(s)
+ −
Add to wish list Ask a question
Product Code
0714750
EAN Code
0606449149777
Manufacturer
NetGear

Quick Specs

Ports
24× 1G RJ45
PoE
16× PoE++ 60W + 8× PoE+ 30W
Budget
480W
Management
Unmanaged (plug-and-play)
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

NETGEAR GS524UP — 24-Port Gigabit Unmanaged PoE++ Switch

24× Gigabit16× PoE++ (60W)480W BudgetPlug-and-Play

The NETGEAR GS524UP is a 24-port Gigabit unmanaged switch with a huge 480W PoE budget, delivering high-power PoE++ on 16 ports and PoE+ on the other 8. It powers demanding devices — PTZ cameras, Wi-Fi 6/6E access points, PoE lighting and displays — with zero configuration in a 1U rackmount chassis. This is part GS524UP-100EUS. Typically in stock with fast delivery across Cyprus.

Compatibility — check before buying:
PoE spans three standards: 16 ports deliver 802.3bt PoE++ up to 60W (Type 3) and 8 ports deliver 802.3af/at PoE+ up to 30W, sharing a 480W budget — so not every port can draw its maximum at once. As an unmanaged switch it has no VLANs or configuration; choose a managed model if you need those. It uses active fans.

Best For

✓High-power PoE++ devices
✓PTZ & pan-tilt cameras
✓Wi-Fi 6/6E tri-band APs
✓PoE lighting & displays
✓Video-intercom & kiosks
✓Plug-and-play deployments

Key Features


16× 60W PoE++ (802.3bt Type 3)
Sixteen ports supply full 60W PoE++ for the most power-hungry devices, with eight more at 30W PoE+ — a 480W budget across all 24 Gigabit ports.

True Plug-and-Play
No setup or software: connect and go, with auto-negotiation and Auto MDI/MDI-X so every device links at the right speed automatically.

Rugged 1U Rackmount Build
A solid metal chassis mounts in a rack or sits on a desk, backed by a NETGEAR limited lifetime warranty for set-and-forget infrastructure.

Smart Traffic & Energy Saving
802.1p / DSCP QoS honouring and 9K jumbo frames keep traffic smooth, while IEEE 802.3az Energy-Efficient Ethernet trims power draw.

Technical Specifications

Identification
Brand NETGEAR
Model GS524UP (Ultra60 PoE++)
Part Number GS524UP-100EUS
EAN / GTIN 0606449149777
MPN GS524UP-100EUS
Ports & Switching
Ports 24 × 10/100/1000 RJ45
Switching Capacity 48 Gbps (non-blocking)
MAC Address Table 8K
Packet Buffer 192 KB
Jumbo Frame 9 KB
Power over Ethernet
PoE Standards IEEE 802.3af / 802.3at (PoE+) / 802.3bt Type 3 (PoE++)
PoE++ Ports 16 × up to 60W
PoE+ Ports 8 × up to 30W
PoE Power Budget 480W
Features
Management Unmanaged (plug-and-play)
QoS 802.1p CoS + DSCP, 8 queues
Energy Saving IEEE 802.3az (EEE)
Physical & Power
Cooling Active (2 fans)
Form Factor 1U rack / desktop, metal
Dimensions 390 × 220 × 43 mm
Weight 3.10 kg
Operating Temp 0–50°C
Power Input 100–240 VAC, 50/60Hz
Max Consumption 578.8W (standby 24.4W)
Warranty
Warranty NETGEAR limited lifetime manufacturer warranty. Singular’s direct warranty is 1 year; beyond that we assist you with the manufacturer’s warranty process.

Frequently Asked Questions

What is the difference between PoE+ and PoE++ here?
This switch has both: 16 ports provide 802.3bt PoE++ up to 60W for high-power devices, and 8 ports provide 802.3af/at PoE+ up to 30W. All 24 share a 480W budget.
Can every port deliver its maximum power at once?
No. The ports share a 480W total budget, so you cannot run all 16 PoE++ ports at a full 60W simultaneously. Plan the budget across your connected devices.
Does it need configuration?
No. The GS524UP is unmanaged and fully plug-and-play — connect your devices and it works, with automatic speed negotiation and PoE detection.
Can I create VLANs on it?
No. As an unmanaged switch it has no VLANs or configuration. If you need VLANs, monitoring or managed control, choose a smart or managed NETGEAR model.
Singular Expert Insight
The GS524UP is one of the few unmanaged switches with real 60W PoE++, making it ideal for PTZ cameras and high-power Wi-Fi 6E APs where a normal PoE+ switch falls short — all with zero setup. If you need VLANs or monitoring, choose a managed PoE model. Browse our network switches range, or the access points and cameras it powers.

Buyer’s Guide

Buy it if
You need high-power PoE — 16 ports at 60W PoE++ plus 8 at 30W, 480W total — to run PTZ cameras, Wi-Fi 6E APs or PoE lighting with zero configuration.
Skip it if
You only power low-draw devices (a PoE+ switch is cheaper), or you need VLANs, monitoring or managed control — choose a managed switch instead.
Also consider
A standard PoE+ switch if your devices need only 30W, or a managed PoE++ switch if you want VLANs and monitoring alongside high-power PoE.
