NETGEAR AV Line M4250-16XF 16-Port 10G AV Switch
16x 10G SFP+320 GbpsAV-over-IP (IGMP Plus)Fanless-selectable
The NETGEAR AV Line M4250-16XF (XSM4216F) is a 16-port managed Layer 3 switch with sixteen 10G SFP+ fibre ports, purpose-built as a high-speed aggregation switch for professional AV-over-IP. Delivering 320 Gbps of switching with NETGEAR's IGMP Plus multicast and pre-loaded Dante, NDI and AES67 profiles, it ties AV endpoints and edge switches into a fast fibre backbone. Typically in stock with fast delivery across Cyprus.
Compatibility — check before buying:
All 16 ports are 10G SFP+ (ports 1-12 also support 1G) and require transceivers or DAC cables (sold separately) - there are no copper RJ45 ports. It is non-PoE, so it aggregates and uplinks rather than powering endpoints. The dedicated AV web GUI simplifies setup; Layer 3 covers static, RIP and PIM multicast routing (no OSPF). Cooling is software-selectable, and can run fanless when conditions allow.
Best For
✓ 10G fibre aggregation for AV-over-IP networks
✓ Core or distribution switch feeding M4250 access switches
✓ Dante, NDI, SVSI and AES67 audio/video backbones
✓ Broadcast, stadiums and large venue AV
✓ Multi-switch multicast domains via IGMP Plus
✓ Fanless-quiet operation in AV control rooms
Key Features
16x 10G SFP+ fibre
Sixteen 10G SFP+ ports (ports 1-12 also 1G-capable) deliver 320 Gbps of switching and 238 Mpps forwarding - a dense all-fibre aggregation layer.
Built for AV-over-IP
IGMP Plus automates multicast across switches, and pre-configured Dante, Q-SYS, AES67, AVB and video (NDI, SVSI, NVX) profiles get AV streams running quickly.
Dedicated AV management UI
A simplified AV interface with colour-based port profiles suits AV installers, while full L2/L3 management remains available for network engineers.
L3 with multicast routing
Static and RIP routing plus PIM-SM/DM/SSM multicast routing extend AV-over-IP across campus-scale, multi-subnet topologies.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
The M4250-16XF is the 10G fibre aggregation member of NETGEAR's AV Line: where the copper M4250 models sit at the edge powering endpoints, this all-SFP+ switch ties them together into a fast, multicast-ready backbone. Its 320 Gbps fabric and IGMP Plus make it a natural core for Dante and NDI installations; if you need copper access with PoE, pair it with M4250 PoE models. Browse our wider network switches range to build out the rest of your AV network.
Buyer's Guide
Buy it if
You need a 16-port 10G SFP+ fibre aggregation switch for professional AV-over-IP, with IGMP Plus, Dante/NDI profiles and multicast routing, without PoE.
Skip it if
You need copper RJ45 ports, PoE to power endpoints, or OSPF dynamic routing - a copper/PoE M4250 or a full L3 switch will fit better.
Also consider
A copper PoE M4250 access switch for endpoints, or a higher M-series switch for larger AV cores.
Features - NetGear - XSM4216F-100EUS
Standard
16-Port
Port Speed
- 10 Gbps
More Details
Product Code
0714775
EAN Code
0606449149708
Manufacturer
NetGear
