Philips 43BDL6017P/00 43-inch 4K UHD Commercial Display
42.5 inches (marketed as 43-inch)UHD 3840 × 2160, optimum 60Hz800 cd/m²Rated 24/7, landscape or portrait
The Philips 43BDL6017P/00 Signage 6000 Series P-Line is a non-touch commercial display for digital signage, with a 42.5-inch visible area, UHD resolution and rated landscape or portrait operation 24/7. USB media playback is built in; the Android player and its memory and storage are optional, not included.
Best For: For shops, hospitality and other signage installations needing a 43-inch-class, 4K display rated for continuous landscape or portrait use. It is a display, not a touch computer or a complete Android signage player.
Before you order: This is a non-touch display. The OPS player, stand, wall bracket, HDMI and network cables, and paid Wave licence are not included. The three power cables are listed, but their plug types are unverified. IP5X is dust protection, not water or weather protection; observe the 0–40°C and 20–80% non-condensing operating limits. Confirm mount load, screw depth, ventilation and orientation. Power figures are typical, maximum and standby ratings, while the EU label states 89kWh/1000h under its regulatory conditions.
What's in the Box
- Display
- AC switch cover
- One Philips logo
- Three power cables (plug types not verified)
- Quick-start guide
- Remote control with AAA batteries
- 3m RS232 cable
- RS232 daisy-chain cable
- USB cover
- Two edge-alignment kits
What It Means in Practice
- The panel is marketed as 43 inches; its visible diagonal is 42.5 inches (108cm). Allow for the stated outer dimensions of 973 × 561.2mm and depth of 76.80mm at the carrying handle or 64.0mm at the wall mount; check clearance with connectors and cables.
- It supports landscape or portrait operation and tiled configurations up to 15 × 15. A compatible content source, control source, bracket and system configuration are required; the tiled capability does not mean multiple displays or guaranteed full 4K across a configured matrix are included.
- USB media playback works with the listed supported formats. Android 14, 8GB RAM and 64GB storage belong to the optional CRD52 OPS player, not the base display.
- The included edge-alignment kits support installation alignment. Verify the mounting surface/load, screw depth, ventilation and orientation for the installation.
What Will Not Work
- Non-touch display.
- The CRD52 OPS player is not included; neither are its Android 14, 8GB RAM or 64GB storage. Philips Wave remote management is optional, and no paid Wave licence is included.
- Stand BM05922, wall bracket, HDMI cable and network cable are not included.
- IP5X indicates dust protection only; the display is not specified as waterproof, washdown-proof, steam-proof or outdoor-weatherproof. Do not rely on kitchen or transport marketing to extend operation beyond 0–40°C and 20–80% RH non-condensing or to justify installation in direct splashes, heat or oil.
- Tiled operation needs compatible content/control sources and system configuration; up to 15 × 15 is a capability, not an included multi-display bundle or assurance of full 4K per panel.
- The energy label's 89kWh/1000h is a regulatory figure and is distinct from 85W typical and 150W maximum power ratings; actual consumption is not fixed by these values.
- Zero image-retention risk and visibility in full outdoor sunlight are not guaranteed.
Key Features
800 cd/m² brightness
A high-brightness specification for commercial signage; it does not establish guaranteed visibility in full outdoor sunlight.
Rated 24/7, landscape or portrait
Supports continuous signage use in either rated orientation, subject to correct installation and operating conditions.
Three HDMI inputs plus HDMI output
Connect up to three HDMI sources and use the separate HDMI output where the compatible configuration supports it.
USB media playback
Play supported video, image and audio formats directly from USB without treating the optional Android OPS player as included.
Technical Specifications
| Manufacturer | Philips |
| Model | 43BDL6017P/00 Signage 6000 Series P-Line |
| Manufacturer SKU | 43BDL6017P/00 |
| EAN | 8721038101188 |
| Display | ADS, 42.5-inch visible / marketed as 43-inch | 16:9 | 3840 × 2160 UHD | optimum 60Hz |
| Brightness | 800 cd/m² |
| Contrast | Typical 1200:1 | dynamic 500000:1 (not native) |
| Response time | 8ms |
| Colours and viewing angles | 1.07 billion colours | 178° viewing angles |
| Haze | 25% |
| Operation and orientation | Rated 24/7 | landscape or portrait |
| Touch | Non-touch display |
| Protection and construction | Metal case | conformal coating | IP5X dust protection; not waterproof |
| Operating conditions | 0–40°C | 20–80% relative humidity, non-condensing |
| Video inputs | 1 × DisplayPort 1.2 | 1 × DVI-I | 3 × HDMI 2.0 |
| Video outputs | 1 × DisplayPort 1.2 | 1 × HDMI 2.0 |
| USB and module slot | 2 × USB 2.0 | OPS slot (module not included) |
| Other connections and sensors | Audio mini-jack in/out | RJ45 control | RS232C in/out, 2.5mm | IR in/out, 3.5mm | ambient-light and thermal sensors |
| Daisy chaining | DisplayPort, HDMI, RS232 and IR, with compatible configuration |
| USB media playback | Supported H.264, H.265, MJPEG, MPEG and WMV video, plus image and audio formats |
| Optional player | CRD52 OPS player: optional; Android 14, 8GB RAM and 64GB storage belong to this player, not the base display |
| Remote management | Philips Wave is optional; compatible special-chipset version can control brightness, volume, standby and power without Android SoC |
| Tiled display capability | Up to 15 × 15; requires compatible content, control source and system configuration |
| Power input | 100–240V AC | 50/60Hz |
| Power consumption | 85W typical | 150W maximum | standby <0.5W |
| EU energy label | EPREL 2281498 | class G | 89kWh/1000h; label identifies PHILIPS43BDL6017P |
| Dimensions (W × H) | 973 × 561.2mm |
| Depth | 76.80mm at carrying handle | 64.0mm at wall mount |
| Weight | 14.12kg |
| Mounting | VESA 200 × 200mm | M6 |
| Bezel | 13.9mm each side |
| Integrated audio | 2 × 10W RMS speakers | 20W total | 3.5mm audio in/out |
| Included items | Display, AC switch cover, one Philips logo, three power cables, quick-start guide, remote with AAA batteries, 3m RS232 cable, RS232 daisy-chain cable, USB cover, two edge-alignment kits |
Frequently Asked Questions
Does it include an Android player?
No. The CRD52 OPS player is optional, and its Android 14, 8GB RAM and 64GB storage are not part of the base display.
How many HDMI inputs does it have?
Three HDMI 2.0 inputs and one HDMI 2.0 output. There are four HDMI sockets in total, not four inputs.
What is included for mounting?
Two edge-alignment kits are listed. A stand and wall bracket are not included; check the installation against the VESA 200 × 200mm M6 specification and the display's dimensions and weight.
Can it be installed outdoors or near water?
IP5X is dust protection, not water or weather protection. The stated operating range is 0–40°C and 20–80% relative humidity, non-condensing; do not infer suitability for direct splashes or outdoor weather.
Singular Expert Insight
The practical draw is the combination of 800 cd/m² brightness, 24/7 rated operation, portrait or landscape orientation and multiple video inputs/outputs. The OPS slot allows an optional player to be added, while USB media playback is available on the base display.
Buyer’s Guide
✓ Buy it if For shops, hospitality and other signage installations needing a 43-inch-class, 4K display rated for continuous landscape or portrait use. It is a display, not a touch computer or a complete Android signage player.
✕ Skip it if This is a non-touch display. The OPS player, stand, wall bracket, HDMI and network cables, and paid Wave licence are not included. The three power cables are listed, but their plug types are unverified. IP5X is dust protection, not water or weather protection; observe the 0–40°C and 20–80% non-condensing operating limits. Confirm mount load, screw depth, ventilation and orientation. Power figures are typical, maximum and standby ratings, while the EU label states 89kWh/1000h under its regulatory conditions.
→ Also consider If you need Android apps or onboard RAM and storage, budget for the optional CRD52 OPS player or another suitably configured source; those components are not included with this display.
