QNAP QGD-1600P / Switch / smart / 4 x 10/100/1000 (PoE++) + 10 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP (PoE+) / rack-mountable / PoE++ (370 W) | QGD-1600P-4G
Product Specification
| Device Type | Switch - 16 ports - smart |
| Enclosure Type | Rack-mountable |
| Subtype | Gigabit Ethernet |
| Ports | 4 x 10/100/1000 (PoE++) + 10 x 10/100/1000 (PoE+) + 2 x combo Gigabit SFP (PoE+) |
| Power Over Ethernet (PoE) | PoE++ |
| PoE Budget | 370 W |
| Performance | Non-blocking bandwidth: 16 Gbps ¦ Switching capacity: 32 Gbps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 9KB |
| Remote Management Protocol | HTTP, CLI |
| Encryption Algorithm | FIPS 140-2, 256-bit AES, AES-NI |
| Features | Flow control, auto-negotiation, trunking, VLAN support, wake on LAN (WOL), IGMP snooping, port mirroring, Access Control List (ACL) support, LACP support, LLDP support, DHCP client, Energy Efficient Ethernet, loop prevention, Software Defined Networking (SDN), schedule PoE, DNS client, port-based VLAN, port-based QoS, SNTP client, DSCP based QoS, PoE Detection |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt |
| Processor | 1 x Intel Celeron: 1.8 GHz |
| RAM | 4 GB (installed) / 8 GB (max) - SO-DIMM 260-pin - DDR4 SDRAM |
| Flash Memory | 4 GB |
| Built-in Devices | Status LCD, 2 x 2.5" SATA 6Gb/s drive bays |
| Status Indicators | PoE, link/activity, speed |
| Interfaces | 4 x 1000Base-T RJ-45 PoE++ - 60 W ¦ 12 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 2 x Gigabit LAN SFP ¦ 1 x HDMI output ¦ 2 x USB 2.0 Type A ¦ 1 x USB 3.0 Type A ¦ 1 x management (LAN) RJ-45 |
| Expansion Slots | 2 (total) / 2 (free) x PCI Express 2.0 |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Power Consumption Operational | 418 Watt |
| Included Accessories | 4 rubber feet, 6 x flat head screws (for 2.5" HDD) |
| Cables Included | 1 x network cable |
| Rack Mounting Kit | Included |
| Compliant Standards | VCCI, BSMI, FCC, RCM |
| Software Included | QTS 4.4.1 |
| OS Required | UNIX, Linux, Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Apple MacOS X 10.7 or later, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 10, Microsoft Windows Server 2016 |
| Weight | 4.41 kg |
| Shipping Width | 52.8 cm |
| Shipping Depth | 40.3 cm |
| Shipping Height | 16 cm |
| Shipping Weight | 5.56 kg |
| Service & Support | Limited warranty - 2 years |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
