QNAP Smart Edge QGD-1602 - Switch - smart - 2 x 10 Gigabit SFP+ + 8 x 2.5GBase-T + 8 x 10/100/1000 - rack-mountable | QGD-1602-C3758-16G
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Switch - 18 ports - smart |
| Enclosure Type | Rack-mountable |
| Subtype | 10 Gigabit Ethernet / 2.5 Gigabit Ethernet |
| Ports | 2 x 10 Gigabit SFP+ + 8 x 2.5GBase-T + 8 x 10/100/1000 |
| Performance | Non-blocking bandwidth: 48 Gbps ¦ Switching capacity: 96 Gbps |
| MAC Address Table Size | 32K entries |
| Routing Protocol | Static IP routing, PPPoE |
| Remote Management Protocol | SNMP 3, SNMP 2c, DHCP |
| Encryption Algorithm | AES-NI |
| Features | VLAN support, IGMP snooping, Quality of Service (QoS), Jumbo Frames support, reset button, LLDP support, 3 fans, Link Aggregation, EXT4 file system, web-based management, Intel QuickAssist Technology (QAT ), loop protection, 8 cores CPU, Disk S.M.A.R.T. Scan, floating point unit, SSD cache acceleration support, Encryption Engine |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3an, IEEE 802.3bz |
| Processor | 1 x Intel Atom C3758: 2.2 GHz |
| RAM | 16 GB (installed) / 64 GB (max) - SO-DIMM 260-pin - DDR4 SDRAM |
| Flash Memory | 4 GB |
| Built-in Devices | Status LCD, 2 x 2.5" SATA 6Gb/s drive bays |
| Status Indicators | Link/activity, fan, speed, warning |
| Expansion / Connectivity | |
| Interfaces | 2 x 10GBase-SR/LR SFP+ ¦ 8 x 1000Base-T RJ-45 ¦ 8 x 2.5GBase-T RJ-45 ¦ 2 x USB 3.2 Gen 1 Type A ¦ 2 x 5Gbit LAN RJ-45 management ¦ 2 x Gigabit LAN RJ-45 management |
| Expansion Slots | 2 (total) / 2 (free) x PCI Express 3.0 x4 ¦ 2 (total) / 2 (free) x M.2 (PCI Express 3.0) |
| Power | |
| Power Device | Internal power supply |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Miscellaneous | |
| Included Accessories | Rubber feet, flat head screws (for 2.5" HDD), power cord |
| Cables Included | 1 x network cable |
| Rack Mounting Kit | Included |
| Compliant Standards | VCCI, BSMI, FCC, RCM, UL 62368, Class A |
| Software / System Requirements | |
| Software Included | QTS 5.0.1 |
| OS Required | UNIX, Linux, Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Apple MacOS X 10.7 or later, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows Server 2022, Microsoft Windows 7 / 8 / 10 / 11 |
| Dimensions & Weight | |
| Width | 43.52 cm |
| Depth | 32.77 cm |
| Height | 4.42 cm |
| Weight | 4.37 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 5.52 kg |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Environmental Parameters | |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 45 °C |
| Humidity Range Operating | 5 - 95% (non-condensing) |
Features - QNAP - QGD-1602-C3758-16G
General
16-Port
More Details
Product Code
04:457645
EAN Code
4711103084267
Manufacturer
QNAP
