Rittal DK 7980.100 — Fan Expansion Kit, 230 V
230 V · 50/60 Hz108 m³/h34 dB(A)119 x 119 mm
The Rittal DK 7980.100 is a fan expansion kit: a single 119 x 119 x 25 mm, 230 V fan with a 0.61 m connection cable and assembly parts, used to add an extra fan to a Rittal fan unit or fan mounting plate. It is meant for IT and network cabinets that already use Rittal fan hardware and need more air movement.
At 50 Hz Rittal rates it at 108 m³/h with 14 W power draw and a noise level of 34 dB(A). At 60 Hz the figures are 120 m³/h and 12 W. It works from -20 to +70 °C.
Before you order: This is an expansion fan, not a complete ventilation unit. It is designed to add to existing Rittal fan hardware. Send us the Rittal part number of your fan unit or mounting plate and we will confirm that this kit fits it.
What's in the Box
- 1x fan unit, 119 x 119 x 25 mm, 230 V
- 1x connection cable, 0.61 m
- Assembly parts
What It Means in Practice
- One more fan in an existing Rittal fan plate raises the air flow through the cabinet by about 108 m³/h at 50 Hz.
- 34 dB(A) is quiet enough for most offices and comms rooms.
- It runs straight from 230 V mains, so no separate power supply is needed.
- The 0.61 m cable is short, so plan where it connects inside the cabinet.
What Will Not Work
- It is not a stand-alone 19-inch fan tray. It has no rack mounting frame of its own.
- It does not include a thermostat or speed control.
- It will not run from 12 V, 24 V or 48 V DC supplies. It is a 230 V AC fan.
- It is not a filter fan for the cabinet door or side panel.
Key Features
230 V AC fan
Connects to mains voltage at 50 or 60 Hz, with 14 W or 12 W power draw.
108–120 m³/h air flow
Rated at 108 m³/h at 50 Hz and 120 m³/h at 60 Hz (with chopped-fibre filter).
Low noise
34 dB(A) at both 50 Hz and 60 Hz.
Wide temperature range
Operating temperature from -20 °C to +70 °C.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
Adding a fan to an existing Rittal fan plate is the cheapest way to lift air flow in a warm cabinet, as long as the unit you already have accepts it. If you are starting from zero, look at a complete fan unit in our rack accessories range, and consider a thermostat so the fans only run when needed.
✓ Buy it if you already have Rittal fan hardware with a free position and want more air flow at 230 V.
✕ Skip it if you need a complete 19-inch fan tray or a DC-powered fan.
→ Also consider a complete 19-inch fan unit with thermostat, or a roof fan for the cabinet.
Not sure it fits your setup? Send us the model of your rack, switch or device and we will check compatibility before you order.
