StarTech.com CPANEL48 Cat6 UTP Patch Panel 48-Port 19 Inch 2U Rackmount 110 Punch-Down T568A/B Steel Black
Brand:
StarTech.com
StarTech.com CPANEL48 Cat6 UTP Patch Panel 48-Port 19 Inch 2U Rackmount 110 Punch-Down T568A/B Steel Black
€177.89 inc. VAT
CPANEL48
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
StarTech.com CPANEL48 — 48-Port Cat6 UTP Patch Panel, 19" 2U
48 portsCat6 UTP19" · 2U110 punch-down
The StarTech.com CPANEL48 is a 48-port Cat 6 unshielded 19-inch 2U patch panel in black. It mounts in a 19-inch rack or cabinet and takes up 2U. Installation cable is punched down on the back with a 110 punch-down tool, and the 48 RJ45 sockets on the front take ordinary patch cords, rated for Gigabit Ethernet (1000Base-T). In practice it gives the cables coming from wall outlets and ceilings a fixed, labelled end point next to your switch, so that moves and changes are made with short patch cords at the panel instead of re-terminating installation cable. If you are planning a new rack, send us the number of outlets and the switch you use — we check that panel, cable and patch cords match before you order.
Compatibility — check before buying:
It is 2U high and UTP Cat6 with a 1 Gbps maximum — not a Cat6A panel; the 24-port 1U version is C6PANEL24. The ports are fixed and terminated with a 110 punch-down tool, which is not in the box. It is unshielded (UTP): use it with U/UTP cable, not in a shielded (STP/FTP) installation. It needs a standard 19-inch rack or cabinet with 2U free. Not sure it matches your cabling? Send us the cable type and the rack or cabinet model and we check it.
Best For
✓ 19-inch server and network racks
✓ Office floor distribution
✓ Structured cabling projects
✓ Patching wall outlets to switches
✓ Data centres and comms rooms
✓ Labelled, serviceable terminations
Key Features
Punch-down termination
110 punch-down blocks with numbered ports and T568A/B colour coding. Once the cable is terminated, every move is made with a patch cord at the front.
Cat 6 performance
Cat6 for 10/100/1000Base-T, maximum 1 Gbps. Unshielded construction keeps installation simple with standard U/UTP cable.
19-inch, 2U
Standard 19-inch width at 2U height, for any network rack or cabinet.
48 ports in 2U
Forty-eight numbered ports on one panel match a 48-port switch, with 2U of height leaving space for fingers and patch cords.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
We suggest the CPANEL48 for 48-port Gigabit switches on U/UTP Cat6 cabling, where a 110 tool is the installer’s standard. Plan the panel with cable and patch cords of the same category, and label the ports as you terminate them. Every order comes with Singular’s local support in Cyprus. See our patch panels or the network switches and network cables that complete the link.
Buyer’s Guide
Buy it if
You need 48 Cat6 UTP ports in 2U and use a 110 punch-down tool.
Skip it if
Your cabling is shielded, you plan 10 Gbit/s, or you have only 1U free.
Also consider
TRENDnet TC-P48C6, a 48-port Cat6 UTP panel with 110D IDC.
Features - StarTech.com - CPANEL48
Colour
black
More Details
Product Code
CQ71754
EAN Code
0065030915076
Manufacturer
StarTech.com
