StarTech.com 1 Port 2.5Gbps PoE Network Card / Low-Profile Bracket Included / NBASE-T | ST1000PEXPSE
Please sign in so that we can notify you about a reply
Product Specification
| Device Type | Network adapter |
| Form Factor | Plug-in card - low profile |
| Interface (Bus) Type | PCI Express 2.1 x1 |
| Networking | Networking |
| Ports | 2.5GBase-T (PoE+) x 1 |
| Connectivity Technology | Wired |
| Cabling Type | Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T, Ethernet 2.5GBase-T, NBase-T |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet |
| Data Transfer Rate | 2.5 Gbps |
| Capacity | Jumbo frame size: 16000 |
| Status Indicators | PoE, link |
| Features | Flow control, full duplex capability, power over Ethernet (PoE), wake on LAN (WOL), Power Sourcing Equipment (PSE), Energy-Efficient Ethernet (EEE), VLAN Tagging, RealWoW! Technology, 30W PoE+ power budget, Automatic Media-Dependent Interface Crossover (MDIX), PXE boot |
| Compliant Standards | IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, IEEE P802.3az |
| Processor / Memory | Processor / Memory |
| Processor | 1 x Realtek Semiconductor RTL8125B |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 1 x 1/2.5GBase-T (PoE+) - RJ-45 ¦ 1 x SATA power - 15 pin Serial ATA power ¦ 1 x SP4 power - 4 pin connector - male |
| Miscellaneous | Miscellaneous |
| Included Accessories | Low-profile bracket, full-height bracket |
| Compliant Standards | RoHS, WEEE, RCM |
| Software / System Requirements | Software / System Requirements |
| Software Included | Drivers & Utilities |
| OS Required | Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8.1 / 10, Microsoft Windows Server 2019, Microsoft Windows 11, Linux Kernel 2.4.20 or later (LTS versions only) |
| Dimensions & Weight | Dimensions & Weight |
| Width | 1.5 cm |
| Depth | 9.5 cm |
| Height | 6.3 cm |
| Weight | 220 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - 2 years ¦ Technical support - assistance - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 50 °C |
| Humidity Range Operating | 5 - 95% RH |
Features - StarTech.com - ST1000PEXPSE
More Details
Product Code
CF58996
EAN Code
0065030893107
Manufacturer
StarTech.com
