StarTech.com OS2MTP12AOFNP10M MTP/MPO-12 OS2 Single-Mode Fibre Cable Type-A Plenum 10 m Yellow

Brand:
StarTech.com
StarTech.com MTP/MPO-12 OS2 Fibre Cable 10 m Yellow
StarTech.com OS2MTP12AOFNP10M MTP/MPO-12 OS2 Single-Mode Fibre Cable Type-A Plenum 10 m Yellow
€250.98 inc. VAT
Buy
OS2MTP12AOFNP10M
€210.91
€250.98 inc. VAT
Ships from EU stock: 5 item(s)
+ −
Add to wish list Ask a question
Product Code
CS58112
EAN Code
0065030930505
Manufacturer
StarTech.com
Quick Specs
Category & fibre
OS2 9/125 single-mode · 12 fibres
Length
10 m
Connectors
MTP/MPO-12 · Type-A (1:1)
Jacket
OFNP plenum · 3 mm · yellow
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

StarTech.com OS2MTP12AOFNP10M MTP/MPO-12 OS2 Fibre Trunk Cable · 10 m

OS2 single-mode · 12F10 m YellowType-A · OFNP plenum40G / 100G

The StarTech.com OS2MTP12AOFNP10M is a 10 m 12-fibre OS2 single-mode MTP/MPO cable for 40G and 100G switch uplinks, server links and structured fibre backbones in data centers. It uses Type-A straight-through (1:1) MTP Elite connectors, Corning 9/125 µm glass and a 3 mm yellow OFNP plenum-rated jacket, so it can be routed through overhead and air-handling spaces.

Compatibility note: Type-A keeps fibre 1 at position 1 on both ends, so transmit/receive polarity must be handled by your cassettes, patch panels or an end-to-end polarity plan. StarTech.com does not state the pin gender (pinned/unpinned) on the listing — confirm it matches your transceivers or cassettes before ordering. Single-mode (OS2) optics only; it will not work with multimode (OM3/OM4) SR optics.

Best For

✓ 40G/100G switch-to-switch uplinks
✓ Server and storage links in high-density racks
✓ MTP cassette and patch panel backbones
✓ Plenum spaces and overhead cable trays

Key Features


12-fibre OS2 single-mode
Corning 9/125 µm glass for 1310 nm and 1550 nm, consolidating 12 fibres into one slim 3 mm trunk for 40G/100G architectures.

Type-A MTP Elite connectors
Straight-through 1:1 fibre mapping end to end; polarity is managed in cassettes or panels, which keeps large deployments consistent.

OFNP plenum jacket
Plenum-rated for air-handling spaces with low smoke; the TIA-standard yellow colour identifies single-mode runs at a glance.

Technical Specifications

Identification
Part Number OS2MTP12AOFNP10M
EAN/GTIN 0065030930505
MPN OS2MTP12AOFNP10M
Brand StarTech.com
Fibre
Fibre Type Single-mode, OS2 — low-loss single-mode class for long reach at 1310/1550 nm
Fibre Size 9/125 µm (Corning glass)
Fibre Count 12 (multifibre MTP/MPO)
Wavelength 1310 nm / 1550 nm
Connectors
Connector 1 MTP/MPO-12 (MTP Elite)
Connector 2 MTP/MPO-12 (MTP Elite)
Polarity Type-A — straight-through, 1:1 fibre positions
Pin Gender Not stated by StarTech.com
Cable
Length 10 m
Outer Diameter 3 mm
Jacket OFNP — Optical Fibre Nonconductive Plenum: rated for air-handling spaces
Colour Yellow
Weight 86 g
Environment
Operating Temperature 0 °C to 70 °C
Storage Temperature -20 °C to 70 °C
Warranty
Warranty Lifetime (StarTech.com), plus free lifetime 24/5 technical support

Frequently Asked Questions

Does the OS2MTP12AOFNP10M work with 100G QSFP28 transceivers?
It suits 100G optics that use a 12-fibre MTP/MPO single-mode interface, such as 100G PSM4, and 40G PLR4/PSM4 optics. Check that your optics are single-mode MTP-12 and confirm the connector gender your transceivers require.
What is the difference between Type-A, Type-B and Type-C MTP cables?
Type-A keeps fibre positions straight through (1 to 1), Type-B reverses them (1 to 12) and Type-C flips pairs. Type-A is common in cassette-based systems where polarity is corrected at the cassettes or patch cords.
Can I use this cable in a ceiling or raised floor?
Yes. The OFNP plenum rating is the highest indoor fire rating for fibre and is suitable for plenum spaces, raised floors and riser runs where local codes accept OFNP.

Singular Expert Insight

The OS2MTP12AOFNP10M is a clean way to build 40G/100G single-mode backbones: one 3 mm trunk replaces six LC duplex runs, and the Type-A layout fits most cassette systems. Check polarity and pin gender before you order — those, not length, cause most MTP mistakes. The 5 m OS2MTP12AOFNP5M is the sibling length.
✓ Buy it if you run single-mode MTP-12 optics or cassettes and need a plenum-rated Type-A trunk.
✕ Skip it if your optics are multimode (OM3/OM4) or your system needs Type-B polarity or a specific pin gender.
→ Also consider OS2 LC-LC duplex patch cables for single links, or a Type-B MTP cable for direct optic-to-optic connections.
