StarTech.com 2 Port Dual Monitor HDMI KVM Switch, 4K 60Hz Ultra HD HDR, Desktop 4K HDMI 2.0 KVM Switch with 2 Port USB 3.0 Hub (5Gbps) & 4x USB 2.0 HID Port, Audio, Hotkey Switching, TAA / KVM with Fast Switching (SV231DHU34K6) / KVM / aud | SV231DHU34K6
Please sign in so that we can notify you about a reply
Product Features
- 4K 60Hz picture and full audio support
The HDMI KVM switch supports resolutions up to 4K at 60 Hz. It drives two large monitors at the full 4K resolution. Includes EDID and HDCP signal emulation so monitors always remain synced for faster switching times, and desktop settings are maintained to avoid disrupting your workflow. With support for digital audio (with supporting displays and sources) and separate 3.5mm stereo audio, the HDMI 2.0 KVM switch delivers full audio compatibility. - Integrated USB hub
The integrated USB 3.0 hub shares two peripherals (in addition to keyboard and mouse) among attached computers as if they were directly connected to your host computer, eliminating the cost of duplicate devices such as printers and scanners. - Easy to operate
The front-panel pushbuttons make it easy to switch between systems and activate the auto-scan feature. The hotkey functionality makes accessing each system quickly, while a buzzer sound confirms the switch.
Special Features
- Supports up to 4K at 60 Hz on two monitors for applications like CAD/CAM, video editing and content creation
- Works with major brands including Dell, HP, and Lenovo
- Includes EDID and HDCP signal emulation so monitors stay synced for faster switching times, and desktop settings are maintained to avoid disrupting your workflow while switching between up to two computers
Product Specification
Device Type | KVM / audio switch - 2 ports |
Enclosure Type | Desktop |
Subtype | KVM |
Ports | 2 x KVM / audio |
Keyboard / Mouse Interface | USB |
Max Resolution | 3840 x 2160 @ 60 Hz |
Features | 7.1 channel audio support, HDR10 support |
Compliant Standards | USB 1.1, USB 2.0, USB 3.0 |
Status Indicators | Status |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | 2 x HDMI output ¦ 4 x HDMI input ¦ 2 x USB 3.0 output Type A ¦ 2 x USB 3.0 input Type B ¦ 4 x USB 1.1 Type A ¦ 2 x audio input mini-jack ¦ 1 x audio output mini-jack ¦ 1 x mini-USB Type B |
Power | Power |
Power Device | External power adapter |
Power Provided | DC 12 V - 3 A |
Voltage Required | AC 100-240 V |
Power Consumption Operational | 36 Watt |
Miscellaneous | Miscellaneous |
Colour | Black |
Included Accessories | 4 rubber feet |
MTBF | 156,000 hours |
Compliant Standards | FCC, RoHS, EDID compatible, HDCP 2.2 |
TAA Compliant | Yes |
Localisation | Japan, New Zealand, North America, United Kingdom, Europe |
Dimensions & Weight | Dimensions & Weight |
Width | 10 cm |
Depth | 16 cm |
Height | 5.8 cm |
Dimensions & Weight (Shipping) | Dimensions & Weight (Shipping) |
Shipping Width | 23.8 cm |
Shipping Depth | 18.9 cm |
Shipping Height | 9.1 cm |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - 2 years |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 40 °C |
Humidity Range Operating | 0 - 80% |
Min Storage Temperature | -10 °C |
Max Storage Temperature | 60 °C |
Features - StarTech.com - SV231DHU34K6
More Details
Product Code
CB93557
EAN Code
0065030881999
Manufacturer
StarTech.com
