StarTech.com 8-Port PCI Express RS232 Serial Adapter Card, PCIe RS232 Serial Card, 16C1050 UART, | PEX8S1050
Please sign in so that we can notify you about a reply
StarTech.com 8-Port PCI Express RS232 Serial Adapter Card, PCIe RS232 Serial Card, 16C1050 UART, Multiport Serial DB9 Controller/Expansion Card, 15kV ESD Protection, Windows & Linux / Up to 921.6 Kbps Baud (PEX8S1050) / Serial adapter / PCIe / RS-232 x 8 / yellow / TAA Compliant | PEX8S1050
Product Specification
| Device Type | Serial adapter |
| Form Factor | Plug-in card |
| Interface (Bus) Type | PCI Express |
| PCI Specification Revision | PCIe 1.1 |
| Ports | RS-232 x 8 |
| Connectivity Technology | Wired |
| Cabling Type | Serial RS-232 |
| Features | Flow control, 16550 UART support, 256-byte FIFO, 1.5KV ESD Protector |
| Processor | ASMedia ASM1083 |
| Interfaces | 8 x RS-232 - 9 pin D-Sub (DB-9) |
| Included Accessories | 8 x hex nuts |
| Cables Included | 1 x DB-62 to DB-9 breakout cable - 48 cm |
| MTBF | 160,013 hours |
| Compliant Standards | RoHS, WEEE |
| Colour | Yellow |
| TAA Compliant | Yes |
| OS Required | Microsoft Windows 98 Second Edition / Windows 2000, Microsoft Windows Server 2003, Microsoft Windows CE 5.0, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows XP / 7 / 8.1 / 10, Microsoft Windows Server 2016, Linux 2.4.x to 4.11.x LTS versions only, Microsoft Windows Server 2019 |
| Width | 1.6 cm |
| Depth | 10.5 cm |
| Height | 12 cm |
| Weight | 74 g |
| Shipping Width | 19 cm |
| Shipping Depth | 2.9 cm |
| Shipping Height | 6.5 cm |
| Shipping Weight | 700 g |
| Service & Support | Limited warranty - lifetime |
| Min Operating Temperature | 0 °C |
| Max Operating Temperature | 55 °C |
| Humidity Range Operating | 5 - 95% |
Features - StarTech.com - PEX8S1050
More Details
Product Code
V935091
EAN Code
0065030888295
Manufacturer
StarTech.com
