Supermicro SuperServer E100-9AP-IA - Barebone - Mini-ITX Box PC - 1 x Atom x5 E3940 - RAM 0 GB - HD Graphics 500 - GigE - black | SYS-E100-9AP-IA
SYS-E100-9AP-IA
Find similar
Delivery
Payment options
Please sign in so that we can notify you about a reply
Special Fetures
- IoT gateway for smart factory/building
- Machine automation
Product Specification
| Type | PC barebone |
| Product Form Factor | Mini-ITX Box PC |
| Colour | Black |
| Processor / Chipset | |
| CPU | Intel Atom x5 E3940 |
| Number of Cores | Quad-Core |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| RAM | |
| Installed Size | 0 GB / 8 GB (max) |
| Technology | DDR3L SDRAM - non-ECC |
| Form Factor | SO-DIMM 204-pin |
| Slots | 1 (Total) / 1 (empty) |
| Features | Unbuffered |
| Hard Drive | |
| Type | No HDD |
| Optical Storage | |
| Type | No optical drive |
| Monitor | |
| Monitor Type | None. |
| Graphics Controller | |
| Graphics Processor | Intel HD Graphics 500 |
| Video Interfaces | VGA, HDMI |
| Networking | |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Ethernet Controller | Intel I210-AT |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Expansion / Connectivity | |
| Slots | 1 (total) / 1 (free) x M.2 Card - 2280 (Key B) ¦ 1 (total) / 1 (free) x Mini PCIe - full-length, full-height |
| Interfaces | 2 x LAN (Gigabit Ethernet) - RJ-45 ¦ 4 x USB 2.0 ¦ 2 x USB 3.0 (2 in front) ¦ 1 x VGA ¦ 1 x HDMI ¦ 4 x serial ¦ 1 x serial - DB-9 |
| Miscellaneous | |
| Compliant Standards | Plug and Play, RoHS, IEC 60068-2-27, IEC 60068-2-64, ACPI 5.0 |
| Power | |
| Device Type | Power adapter |
| Voltage Required | DC 12 V |
| Power Provided | 60 Watt |
| Operating System / Software | |
| OS Provided | No operating system |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - labour - 3 years ¦ Limited warranty - parts - 1 year |
| Dimensions & Weight | |
| Width | 19.4 cm |
| Depth | 12.6 cm |
| Height | 8 cm |
| Weight | 1.5 kg |
| Dimensions & Weight (Shipping) | |
| Shipping Width | 24.1 cm |
| Shipping Depth | 20.3 cm |
| Shipping Height | 14 cm |
| Shipping Weight | 1.8 kg |
| Environmental Parameters | |
| Min Operating Temperature | -20 °C |
| Max Operating Temperature | 60 °C |
| Humidity Range Operating | 8 - 90% (non-condensing) |
Features - SUPERMICRO - SYS-E100-9AP-IA
More Details
Product Code
04:375055
EAN Code
0672042305391
Manufacturer
SUPERMICRO
