TP-Link Omada SG3210XHP-M2 8-Port 2.5G PoE+ Managed Switch - 2 x 10G SFP+
The TP-Link Omada SG3210XHP-M2 is a managed L2+ rack switch for Omada-based networks. It offers 8 x 2.5G RJ-45 PoE+ ports, 2 x 10G SFP+ slots, cloud management and a 240W total PoE budget, making it a strong fit for wired network expansion where higher-speed copper access and fibre uplinks are needed.
Technical Specifications
| Specification | Detail |
|---|---|
| Product Type | Switch |
| Switch Type | Managed |
| Switch Layer | L2+ |
| Build Type | Rack module |
| Rack Height | 1 U |
| Colour | Black |
| Basic Switching RJ-45 Ethernet Ports | 8 |
| RJ-45 Port Type | 2.5G Ethernet (100/1000/2500) |
| 2.5G Ethernet (Copper) Ports | 8 |
| SFP+ Module Slots | 2 |
| Console Port | RJ-45/micro-USB |
| PoE | Yes |
| PoE+ Ports | 8 |
| PoE Power per Port | 30 W |
| Total PoE Budget | 240 W |
| Switching Capacity | 80 Gbit/s |
| Forwarding Rate | 59.52 Mpps |
| MAC Address Table | 16000 entries |
| Jumbo Frames | 9000 |
| Packet Buffer Memory | 12 MB |
| Static Routes | 48 |
| IP Interfaces | 16 |
| VLANs | 4000 |
| VLAN Features | MAC address-based VLAN | Port-based VLAN | Private VLAN | Protocol-based VLAN | Tagged VLAN | Voice VLAN |
| Management | Web-based management | Cloud-managed |
| Network Protocol | SNTP |
| Management Protocols | SNMPv1/v2c/v3 | SNTP |
| QoS Support | Yes |
| Traffic Classification | Yes |
| ARP Inspection | Yes |
| CLI Support | Yes |
| System Event Log | Yes |
| Port Mirroring | Yes |
| IP Routing | Yes |
| Static Routing | Yes |
| Link Aggregation | Yes |
| Broadcast Storm Control | Yes |
| Rate Limiting | Yes |
| Spanning Tree Protocol | Yes |
| Flow Control | Yes |
| Head-of-Line Blocking | Yes |
| GVRP | Yes |
| Multicast Support | Yes |
| MLD Snooping | Yes |
| IGMP Snooping | Yes |
| DHCP Features | DHCP client | DHCP relay | DHCP server | DHCP snooping | DHCPv6 client | DHCPv6 snooping |
| Security | HTTPS | SSH | SSH-2 | SSL/TLS |
| Access Control | ACL support | MAC address filtering | Static port security | IP-MAC-Port binding |
| Authentication | MAC-based authentication | Port-based authentication | AAA | TACACS+ |
| Protection | Loop protection | BPDU filtering/protection | Password protection |
| Queue Scheduling | SP | WRR+SP | Weighted Round Robin (WRR) |
| Power Source | AC |
| Power Supply Included | Yes |
| AC Input Voltage | 100 - 240 V |
| AC Input Frequency | 50/60 Hz |
| Power Consumption (Max) | 285.9 W |
| Fans | 2 fan(s) |
| LED Indicators | Yes |
| Operating Temperature | 0 - 45 °C |
| Operating Relative Humidity | 10 - 90 % |
| Dimensions | 440 x 180 x 44 mm |
| Heat Dissipation | 975.54 BTU/h |
| Certification | CE | FCC | RoHS |
| Manufacturer SKU | SG3210XHP-M2 |
| EAN/UPC | 6935364030797 |
| Power | 285.9 W |
| Data Transfer Rate | 0.1 Gbps |
| SKU / EAN | SG3210XHP-M2 | 6935364030797 |
SINGULAR RECOMMENDS
For who
For businesses, offices and installers that need a managed 2.5G access switch with PoE+ power, cloud management and 10G fibre uplinks.
Real reason to buy it
It combines 8 x 2.5G PoE+ ports, 2 x 10G SFP+ slots and a 240W PoE budget in a managed Omada platform for flexible network expansion.
Know before
This is a 1U rack switch with AC power. The listed maximum power consumption is 285.9W, and the product uses 2 x 10G SFP+ module slots rather than pre-installed SFP+ modules.
