TP-Link Omada SM6110-LR SFP28 Transceiver 25GBASE-LR and 10GBASE-LR 1310 nm LC Single-Mode up to 10 km DDM
Brand:
TP-LINK
TP-Link Omada SM6110-LR SFP28 Transceiver 25GBASE-LR and 10GBASE-LR 1310 nm LC Single-Mode up to 10 km DDM
€147 inc. VAT
SM6110-LR(UN)
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
TP-Link Omada SM6110-LR — 25G/10G LR SFP28, 10 km
25 / 10 GbpsSFP28 LRSingle-mode 10 kmDDM
The TP-Link Omada SM6110-LR is a dual-rate SFP28 transceiver that runs 25GBASE-LR or 10GBASE-LR at 1310 nm over single-mode fibre up to 10 km, through a duplex LC UPC connection with digital diagnostics. TP-Link lists it for the SX6632YF at 25G and for the SG3428X and SG3452X at 10G, so one optic covers both generations of Omada uplinks. In practice, single-mode optics are the choice when a link leaves the building or runs several hundred metres: the OS2 fibre used by carriers and campus backbones carries the signal for kilometres with little loss. Before you order, confirm the fibre is single-mode at both ends and note the length and the number of patch panels on the way.
Compatibility — check before buying:
It needs single-mode fibre and an LR module at the far end running the same speed — a 25G port facing a 10G port settles at 10G only if both ends support it. It will not work on multimode fibre; TP-Link’s SM6110-SR is the 850 nm multimode version, and the TL-SM5110-LR is a 10G-only LR module. Keep the dust cap on until you connect the fibre, and clean both connector ends before every mating — dirt is the most common cause of a link that will not come up. Not sure? Send us your device model and the cable run and we check it before you order.
Best For
✓ 25G uplinks on the Omada SX6632YF
✓ 10G uplinks on SG3428X and SG3452X
✓ Links between buildings up to 10 km
✓ Mixed 10G and 25G Omada networks
✓ Single-mode campus backbones
✓ Spare optics for Omada switches
Key Features
One optic, two speeds
Runs at 25G in SFP28 ports and at 10G in SFP+ ports, so it outlives an upgrade from 10G to 25G.
Single-mode fibre, long reach
Built for single-mode (OS1/OS2) fibre, the type used between buildings, floors and sites. It will not run over the orange or aqua multimode fibre found in many racks — the fibre type has to match at both ends.
Monitoring you can read
Digital diagnostics (DDM) let the host report temperature, laser power and received light, so a dirty connector or a failing link shows up before users call.
Hot-swappable
Modules and cables plug into a live port without shutting the switch down, so a link can be added or replaced during working hours. Seat it until it clicks and use the latch or pull tab to remove it.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
We offer the SM6110-LR for Omada networks that link buildings today at 10G and plan to move to 25G: the same optic works in both port types. Check that every patch cord is single-mode UPC. For runs inside one room, the SR version is cheaper. Every order is backed by Singular’s local support in Cyprus — if a link will not come up, send us the port status and we help you find out whether it is the module, the cable or the configuration. Browse all transceivers and DAC cables or the switches they plug into.
Buyer’s Guide
Buy it if
You need 10G or 25G over single-mode fibre up to 10 km on TP-Link Omada switches.
Skip it if
Your fibre is multimode, or the far end is an SR module.
Also consider
TP-Link SM6110-SR for multimode runs.
Features - TP-LINK - SM6110-LR(UN)
More Details
Product Code
04:469386
EAN Code
8885020622355
Manufacturer
TP-LINK
