TP-Link Omada SG5452X | 48-Port Managed L3 Switch | 4x 10G SFP+ | 34.1 W | SNMP
The TP-Link Omada SG5452X is a managed Layer 3 switch for access-layer networking, with 48 Gigabit RJ45 ports, 4 x 10 Gbps SFP+ slots and centralised management. It is built for rack mounting and includes stackable design, web-based management and cloud management options.
Technical Specifications
| Specification | Detail |
|---|---|
| Switch Type | Managed |
| Switch Layer | L3 |
| RJ-45 Ethernet Ports | 48 x Gigabit Ethernet (10/100/1000) |
| SFP+ Slots | 4 |
| 10G Support | Yes |
| Switching Capacity | 176 Gbit/s |
| Bandwidth | 88 Gbit/s |
| Forwarding Rate | 130.94 Mpps |
| MAC Address Table | 16000 entries |
| VLAN Support | Yes |
| VLAN Features | MAC address-based VLAN | Private VLAN | Protocol-based VLAN | Voice VLAN |
| Number of VLANs | 4000 |
| Link Aggregation | Yes |
| Port Mirroring | Yes |
| Broadcast Storm Control | Yes |
| Multicast Support | Yes |
| DHCP Features | DHCP relay | DHCP server |
| ACL | Yes |
| IGMP Snooping | Yes |
| MAC Address Filtering | Yes |
| Static Port Security | Yes |
| IP-MAC-Port Binding | Yes |
| SSH/SSL Support | Yes |
| Password Protection | Yes |
| Console Port | RJ-45 |
| USB Ports | 1 x USB 2.0 | 1 x USB Type-C |
| Management | Web-based management | Cloud-managed | Telnet | Firmware upgradeable |
| Stacking | Stackable | Physical stacking (up to 4 units) |
| Processor | ARM | 1200 MHz |
| Memory | 2000 MB DRAM |
| Flash Memory | 512 MB |
| Packet Buffer Memory | 12 MB |
| Store-and-Forward | Yes |
| Jumbo Frames | Supported | 9000 |
| Fanless | Yes |
| Power | 34.1 W |
| Power Source | AC |
| Power Supply | Included |
| AC Input Voltage | 100 - 240 V |
| AC Input Frequency | 50/60 Hz |
| Surge Protection | Yes | 6 kV |
| Rack Mounting | Yes |
| Rack Mount Kit | Included |
| Cables Included | AC |
| LED Indicators | Yes |
| Colour | Black |
| Dimensions | 440 x 220 x 44 mm |
| Compliance Certificates | CE | FCC | RoHS |
| Security | SNMP | SNMPv2 | SNMPv3 |
| SKU / EAN | SG5452X | 8885020626469 |
SINGULAR RECOMMENDS
For who
Suitable for teams that need a managed access-layer switch with 48 Gigabit ports, 10G uplinks and Layer 3 functionality in a rack-mounted setup.
Real reason to buy it
The main value is the mix of 48 Gigabit ports, 4 x 10G SFP+ slots and Layer 3 management in one centrally managed switch.
Know before
This model does not include PoE. The confirmed power figure is 34.1 W, and it uses AC power with the supplied power supply included.
Features - TP-LINK - SG5452X(UN)
Standard
48-Port
Port Speed
- 10/100 Mbps,
- 1 Gbps,
- 10 Gbps
More Details
Product Code
CO60059
EAN Code
8885020626469
Manufacturer
TP-LINK
