TP-Link Omada POE10R TL-POE10R Gigabit PoE Splitter IEEE 802.3af 5V 9V 12V Selectable DC Output up to 12W 100 m

Brand:
TP-LINK
TP-Link POE10R Gigabit PoE Splitter 802.3af 5/9/12V
TP-Link Omada POE10R TL-POE10R Gigabit PoE Splitter IEEE 802.3af 5V 9V 12V Selectable DC Output up to 12W 100 m
€24.23 inc. VAT
Buy
POE10R
€20.36
€24.23 inc. VAT
Ships from EU stock: 14 item(s)
+ −
Add to wish list Ask a question
Product Code
CJ89239
EAN Code
1210002610285
Manufacturer
TP-LINK

Quick Specs

Input
IEEE 802.3af PoE
DC output
5 V 2 A / 9 V 1 A / 12 V 1 A
Data
Gigabit, up to 100 m
Size
80.8 x 54 x 24 mm
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

TP-Link POE10R — power a non-PoE device from your PoE network

802.3afGigabit5 / 9 / 12 VPlug and play

The TP-Link POE10R (formerly TL-POE10R, now sold as the Omada PoE Splitter) takes power and data from one PoE cable and splits them for a device that has no PoE of its own. The PoE input accepts IEEE 802.3af power, the LAN output passes Gigabit data, and the DC output can be set to 5 V, 9 V or 12 V — up to 10 W at 5 V, 9 W at 9 V or 12 W at 12 V. It works up to 100 m from the PoE source and measures 80.8 x 54 x 24 mm.

Compatibility — check before buying:
The POE10R does not create power: it needs an 802.3af/at PoE switch or injector upstream. Set the voltage selector to your device’s voltage before connecting — the wrong setting can damage it. Output is limited to 12 W at 12 V (1 A), so it will not run devices that need more power or 24/48 V. TP-Link does not publish the DC plug size; check that the included DC cable fits your device. Tell us the exact model you have and we check compatibility before you order.

Best For

✓ Non-PoE IP cameras
✓ Small routers and access points
✓ Devices far from a power socket
✓ Ceiling and outdoor-cabinet installs
✓ Pairing with a PoE injector
✓ Offices with PoE switches

Key Features


Three output voltages
Selectable 5 V 2 A, 9 V 1 A or 12 V 1 A DC.

Gigabit data
10/100/1000 Mbps on both RJ45 ports, so data speed is not reduced.

Up to 100 m
Place the device up to 100 m from the PoE switch or injector.

Plug and play
802.3af compliant, no configuration needed.

Technical Specifications

Identification
Brand TP-Link
Product POE10R Omada PoE Splitter (TL-POE10R)
Part Number TL-POE10R / POE10R
EAN / GTIN 1210002610285
Type 802.3af Gigabit PoE splitter
Current name POE10R | Omada PoE Splitter
Ports
PoE In 1x RJ45 10/100/1000 Mbps
LAN Out 1x RJ45 10/100/1000 Mbps
DC Out 1x DC power output
Power
Input IEEE 802.3af PoE
Output 5 VDC 2 A / 9 VDC 1 A / 12 VDC 1 A, selectable
Max output 10 W at 5 V, 9 W at 9 V, 12 W at 12 V
Physical & Environment
Dimensions 80.8 x 54 x 24 mm
Distance Up to 100 m
Operating temperature 0 to 40 °C
Certifications FCC, CE, RoHS
In the Box
Included POE10R splitter, DC output cable, Cat5e cable, installation guide
Not Included PoE switch or injector, power adapter, device to be powered
Warranty
Warranty 1-Year Warranty (Singular)
Manufacturer Term TP-Link’s UK warranty page lists 2 years for accessories, with a footnote giving 1 year for accessories of SOHO/SMB products; that manufacturer service covers the UK and Ireland. Singular’s direct warranty is 1 year; beyond that we assist you with the manufacturer’s warranty process for its full duration.

Frequently Asked Questions

Does it need a PoE switch?
Yes, or a PoE injector. The splitter only takes power from the network cable.
Which voltages does it output?
5 V (2 A), 9 V (1 A) or 12 V (1 A), set with the selector.
Is the data Gigabit?
Yes, both network ports are 10/100/1000 Mbps.
Is this the same as TL-POE10R?
Yes. TP-Link now sells it as POE10R, the Omada PoE Splitter.
Singular Expert Insight
The splitter is the easy fix when a camera or small router sits where there is only a network cable. Pair it with an 802.3af PoE switch from our PoE switches or a TP-Link PoE injector, set the voltage first, and check the DC plug. More power parts are in our networking accessories.

Buyer’s Guide

Buy it if

you want to power a 5, 9 or 12 V device over its network cable.

Skip it if

your device already supports PoE, or it needs more than 12 W.

Also consider

TP-Link POE150S / TL-POE150S PoE injector.
