TP-Link Omada SM331T 1000BASE-T RJ-45 SFP Module Gigabit Copper Transceiver up to 100 m Cat5e

Brand:
TP-LINK
TPLink TL-SM331T V1 SFP (mini-GBIC) transceiver TL-SM331T
TP-Link Omada SM331T 1000BASE-T RJ-45 SFP Module Gigabit Copper Transceiver up to 100 m Cat5e
€36.89 inc. VAT
Buy
SM331T
€31.00
€36.89 inc. VAT
Ships from EU stock: 3 item(s)
+ −
Add to wish list Ask a question
Product Code
CJ89224
EAN Code
4897098687741
Manufacturer
TP-LINK

Quick Specs

Speed
1 Gbps (1000BASE-T)
Port
RJ-45 copper
Cable & Reach
Cat5e · up to 100 m
Power
0.8 W max.
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

TP-Link Omada SM331T — Gigabit RJ-45 SFP Module

1 Gbps1000BASE-TRJ-45 copperUp to 100 m

The TP-Link Omada SM331T (TL-SM331T) is a copper SFP module that turns an SFP slot into a Gigabit RJ-45 port, reaching up to 100 m over Cat5e or better cable. It draws 0.8 W at most and lets a spare SFP port on an Omada router or switch connect a server, access point, NVR or other copper device without a media converter. In practice, a copper module is the quickest way to connect a nearby device that only has an RJ-45 port. Use fibre for anything beyond the copper reach shown in the table.

Compatibility — check before buying:
It is a Gigabit module: TP-Link’s current Omada pages list 10/100/1000BASE-T operation in host systems, while the V1.0 datasheet lists 1000BASE-T only — so a 10 or 100 Mbps device depends on the host port. TP-Link’s compatibility list names the ER8411 and ER7206 routers. It needs an SFP slot; for 10G copper in an SFP+ slot, the SM5310-T is the sibling. Not sure? Send us your switch model and the cable run and we check it before you order.

Best For

✓ Spare SFP ports on Omada routers
✓ Copper devices near an SFP switch
✓ Access points, NVRs and servers
✓ Mixed fibre and copper uplinks
✓ Cat5e runs up to 100 m
✓ Replacing a failed SM331T

Key Features


RJ-45 from an SFP slot
Adds a Gigabit copper port to an SFP slot, up to 100 m over Cat5e, without a separate media converter.

Copper instead of fibre
Turns an SFP cage into an RJ-45 port, so the switch can reach a server, NVR, access point or other device over ordinary twisted-pair cable, without a separate media converter.

Hot-swappable
Modules plug into a live port without shutting the switch down, so a link can be added or replaced during working hours. Seat it until it clicks and use the latch to remove it.

Plan both ends together
A link only comes up when both ends use the same standard, speed and media. Order the far-end module, the patch cords and any spares in one go and the link works on day one.

Technical Specifications

Identification
Brand TP-Link (Omada)
Model Omada 1000BASE-T RJ45 SFP Module SM331T (TL-SM331T), V1
Part Number SM331T(UN)
EAN / GTIN 4897098687741
Pack Size Single unit
Interface
Form Factor SFP (mini-GBIC), metal enclosure
Standard 1000BASE-T (IEEE 802.3ab)
Data Rate 1 Gbps
Connector RJ-45
Media & Reach
Cable Cat5e or better
Reach Up to 100 m (TP-Link lab figure)
10/100 Mbps Current Omada pages list 10/100/1000BASE-T in host systems; the V1.0 datasheet lists 1000BASE-T only
Environment & Power
Operating Temperature 0 to 70 °C
Power Consumption 0.5 W typical · 0.8 W max.
Supply Voltage 3.3 V
Size 67.4 × 13.75 × 13.8 mm
Compatibility
Designed For SFP ports on TP-Link Omada devices; TP-Link’s compatibility list names the ER8411 (SFP ports) and ER7206 routers
Link Partner A Gigabit RJ-45 port within 100 m
In the Box
Included the SM331T module and an Installation Guide
Not Included Network cable
Warranty
Warranty 1-Year Warranty (Singular)
Manufacturer Term TP-Link does not state a warranty term for this module on its product page or datasheet. Singular’s direct warranty is 1 year; beyond that we assist you with the manufacturer’s warranty process.

Frequently Asked Questions

Will it connect a 100 Mbps device?
TP-Link’s current pages list 10/100/1000BASE-T in host systems, but the V1.0 datasheet lists 1000BASE-T only. It depends on the host port — send us the model and the device and we check.
Which TP-Link devices take it?
TP-Link’s compatibility list names the ER8411 (SFP ports) and ER7206 Omada routers. For other switches, send us the model.
Is anything else needed to make the link?
A Cat5e or better cable of up to 100 m to the device, and a free SFP port. Tell us the switch and the device and we check it.
Will it work in a switch from another brand?
TP-Link sells the module for its own Omada devices and does not publish operation in other brands’ switches, so we do not promise it — send us the model and we check it.
Singular Expert Insight
We fit the SM331T when an Omada router or switch has a spare SFP slot and a nearby device only has RJ-45. Keep the run within 100 m on Cat5e or better. For 10G copper on SFP+ ports, the SM5310-T is the right module. Every order is backed by Singular’s local support in Cyprus — if a link will not come up, send us the port status and we help you find out whether it is the module, the cable or the configuration. Browse all transceivers or the switches they plug into.

Buyer’s Guide

Buy it if

You need a Gigabit RJ-45 port from an SFP slot on a TP-Link Omada device, within 100 m.

Skip it if

The device runs below 1G on a host that does not support it, or you need 10G copper (SM5310-T).

Also consider

TP-Link SM5310-T for 10G copper on SFP+.
