Industrial routing, Wi-Fi and PoE+ device power
AC1200 dual-band4× Gigabit PoE+ LAN1× Gigabit WANIP30 / DIN rail
The TRENDnet TI-WP100 combines dual-band AC1200 wireless routing with four Gigabit PoE+ LAN ports and one Gigabit WAN port. Its metal DIN-rail enclosure, redundant power inputs, VLAN/VPN functions and serial Modbus interface support suitable industrial network installations. The external power supply is purchased separately.
Best For: Industrial cabinets and managed small-site networks needing wireless connectivity, Gigabit routing and power for compatible PoE devices.
Before you order: Power supply sold separately. The guide states up to 20 W for the router without PoE and up to 120 W PoE output, requiring up to 140 W total input capacity for the full budget. Select a suitable approved supply for the intended load and installation. IP30 is not waterproof. Wi-Fi performance is degraded above 60°C despite the wider operating range.
What's in the Box
- TI-WP100 router, four detachable dual-band antennas and quick installation guide.
- 1.5 m network cable, 8-pin power/digital I/O terminal block, 4-pin serial terminal block and DIN-rail mounting bracket.
- Power supply, 35 mm rail, optional TEW-LB101 magnetic antenna bases, modem/internet service and PoE client devices are separate.
What It Means in Practice
- Plan the DC supply and total PoE load before installation; follow the official guide and suitable industrial installation practice.
- Mount using the supplied DIN-rail bracket and maintain appropriate enclosure ventilation and grounding.
- Connect a compatible modem/network to the Gigabit WAN and suitable PoE devices to the four LAN ports.
- Configure supported Ethernet/wireless WAN failover or load balancing, VLANs and access policies.
- Use supported IPsec/OpenVPN, monitoring and Modbus features only with matching network and application requirements.
What Will Not Work
- The router is not supplied with a power supply and cannot reserve the full PoE budget without sufficient input headroom.
- Four PoE+ outputs support up to 30 W per port within the 120 W total budget and available supply.
- IP30 protects a suitably installed indoor device; it is not a water-resistant outdoor enclosure.
- AC1200 combines theoretical 300 Mbps at 2.4 GHz and 867 Mbps at 5 GHz; actual throughput is lower. Wi-Fi degrades above 60°C.
Key Features
Four powered LAN connections
Gigabit 802.3af/at PoE outputs, up to 30 W each within the 120 W total budget.
Wired and wireless WAN
Gigabit Ethernet WAN and supported wireless WAN offer load-balancing or failover arrangements.
Industrial interfaces
DIN-rail mounting, redundant power inputs, digital I/O and RS232/RS485 Modbus support.
Managed network controls
VLAN mapping, inter-VLAN routing, QoS, VPN and SNMP provide supported administrative tools.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
Size the installation around the power budget and environment first. PoE output is additional to router consumption, and each powered device contributes to the total. A protected cabinet, suitable supply, antenna placement and a tested WAN failover policy matter more than the combined wireless rate.
Buyer’s Guide
✓ Buy it if You need industrial wireless routing with four PoE+ outputs, DIN-rail mounting and supported management interfaces.
✕ Skip it if You need an included adapter, water-resistant outdoor enclosure, built-in cellular modem or newer Wi-Fi generation.
→ Also consider Supply capacity, DC installation, PoE loads, cabinet temperature, antenna placement and compatible WAN/VPN devices.
Features - Trendnet - TI-WP100
Colour
black
Interface
- USB2.0,
- Ethernet,
- WIFI
Standard
5-Port
Port Speed
- 1 Gbps
More Details
Product Code
04:450086
EAN Code
0710931161632
Manufacturer
Trendnet
