Product Features
- Easy installation
No configuration needed, simply connect network devices to the industrial Ethernet switch. - Redundant power
The industrial Ethernet switches feature dual power inputs to provide redundant power with overload current protection. - Industrial hardened design
Equipped with a rugged IP30 rated housing, and designed to withstand a high degree of vibration and shock, while operating within a wide temperature range of -40° - 75° C (-40° - 167° F). - Grounding point
Grounding point on each industrial Ethernet switch designed to protect equipment from external electrical surges.
Special Features
- 5 x Fast Ethernet ports
- 1Gbps switching capacity
- Hardened IP30 rated metal switch
- Wide operating temperature range of -40° - 75° C (-40° - 167° F)
- Dual inputs provide redundant power with overload current protection
- Fanless design for silent operation
Product Specification
| Device Type | Switch - 5 ports - unmanaged |
| Enclosure Type | DIN rail mountable, wall-mountable |
| Subtype | Fast Ethernet |
| Ports | 5 x 10/100 |
| Performance | Switching capacity: 1 Gbps ¦ Forwarding performance (64-byte packet size): 0.744 Mpps |
| MAC Address Table Size | 1K entries |
| Features | Half duplex mode, full duplex mode, fanless, 56KB packet buffer, 8KV ESD Protector |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 5 x 100Base-T RJ-45 |
| Power | Power |
| Power Device | External power adapter (not included) |
| Max Supported Qty | 2 |
| Power Redundancy | Yes |
| Voltage Required | DC 12 - 56 V |
| Power Consumption Operational | 2.24 Watt |
| Miscellaneous | Miscellaneous |
| Included Accessories | DIN-rail mounting kit, wall mounting kit, removable terminal block |
| MTBF | 510,304 hours |
| Compliant Standards | IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, FCC, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, IP30 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 3.2 cm |
| Depth | 8.2 cm |
| Height | 10.4 cm |
| Weight | 486 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
Features - Trendnet - TI-E50
General
5-Port
More Details
Product Code
04:328595
EAN Code
0710931161755
Manufacturer
Trendnet
