TRENDnet TI-PG102I / Switch / Managed / 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP / DIN rail mountable / PoE+ (240 W) / DC power | TI-PG102I
Please sign in so that we can notify you about a reply
Special Features
- Hardened metal switch
- Dual redundant power inputs with overload current protection
- Alarm output triggered by power failure
Product Specification
| Device Type | Switch - 10 ports - Managed |
| Enclosure Type | DIN rail mountable |
| Subtype | Gigabit Ethernet |
| Ports | 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| PoE Budget | 240 W |
| Performance | Switching capacity: 20 Gbps ¦ Forwarding performance (64-byte packet size): 14.88 Mpps |
| Capacity | VLAN groups: 256 ¦ Multicast groups: 256 |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10KB |
| Routing Protocol | RSTP, STP |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, Telnet, SNMP 3, SNMP 2c, HTTP, SSH-2, CLI |
| Authentication Method | RADIUS |
| Features | VLAN support, IGMP snooping, Syslog support, port mirroring, store and forward, Broadcast Storm Control, half duplex mode, full duplex mode, Multicast Storm Control, SNTP support, Weighted Fair Queuing (WFQ), Digital Diagnostics Monitoring Interface (DDMI), Spanning Tree Protocol (STP) support, Rapid Spanning Tree Protocol (RSTP) support, DHCP snooping, Quality of Service (QoS), RADIUS support, Dynamic ARP Inspection (DAI), reset button, bandwidth control, LACP support, LLDP support, DHCP relay, Port Security, over-current protection, SNMP trap, Management Information Base (MIB), Strict Priority Queuing (SPQ), port isolation, Class of Service (CoS), Strict Priority (SP), tagged VLAN, 8KV ESD Protector, ONVIF support, metal housing, SNMP support, DiffServ Code Point (DSCP) support, shock-resistant, vibration-proof, IP source guard, ARP inspection, 6KV Surge protection, Link Aggregation, Management Information Base (MIB) II, MAC address learning, IGMP querier, Ethernet Ring Protection Switching (ERPS) v2, IGMP fast leave, BPDU Filter, Weighted Round Robin (WRR), MAC based VLAN, loopback detection, chassis ground lug, traffic monitoring, 10 KB Jumbo Frame, BPDU Guard, queue scheduling support |
| Compliant Standards | IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX |
| RAM | 128 MB |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 8 x 1000Base-T RJ-45 PoE+ ¦ 2 x 1000Base-FX SFP |
| Power | Power |
| Power Device | Internal power supply |
| Power Redundancy | Yes |
| Voltage Required | DC 24 - 57 V |
| Miscellaneous | Miscellaneous |
| Included Accessories | DIN-rail mounting kit |
| MTBF | 562,234 hours |
| Compliant Standards | FCC, IP30, EN 60068-2-27, EN 60068-2-32, EN 60068-2-6 |
| Dimensions & Weight | Dimensions & Weight |
| Width | 5 cm |
| Depth | 12 cm |
| Height | 16 cm |
| Weight | 930 g |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 75 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
Features - Trendnet - TI-PG102I
General
8-Port
More Details
Product Code
04:288637
EAN Code
0710931161342
Manufacturer
Trendnet
