Home/Networking/Switch - Bridges/TRENDnet TI-PGM102 / Switch / industrial / 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP / DIN rail mountable, wall-mountable / PoE+ (240 W) / TAA Compliant | TI-PGM102

TRENDnet TI-PGM102 / Switch / industrial / 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP / DIN rail mountable, wall-mountable / PoE+ (240 W) / TAA Compliant | TI-PGM102

TRENDnet TIPGM102 Switch industrial TIPGM102

Description
Features

Product Specification

Device Type	Switch - 10 ports
Enclosure Type	DIN rail mountable, wall-mountable
Subtype	Gigabit Ethernet
Ports	8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP
Power Over Ethernet (PoE)	PoE+
PoE Budget	240 W
Performance	Switching capacity: 20 Gbps Â¦ Forwarding rate (64-byte packets): 14.88 Mpps Â¦ Buffer memory: 1.5 MB
MAC Address Table Size	4K entries
Jumbo Frame Support	9KB
Features	Auto-negotiation, store and forward, half duplex mode, full duplex mode, over-current protection, rugged, Jumbo Frames support (up to 9000 bytes)
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at
Expansion / Connectivity	Expansion / Connectivity
Interfaces	8 x Gigabit LAN RJ-45 PoE+ - 30 W Â¦ 2 x 1000Base-FX SFP
Power	Power
Power Device	External power adapter (not included)
Max Supported Qty	2
Power Redundancy	Yes
Power Provided	48 - 55 V
Power Consumption Operational	6.38 Watt
Miscellaneous	Miscellaneous
Included Accessories	Removable terminal block
MTBF	1,000,000 hours
Compliant Standards	IEC 61000-4-2, IEC 61000-4-4, IEC 61000-4-5, FCC, LVD, IP30, NDAA
TAA Compliant	Yes
Dimensions & Weight	Dimensions & Weight
Width	21 cm
Depth	16 cm
Height	4.5 cm
Weight	1.1 kg
Manufacturer Warranty	Manufacturer Warranty
Service & Support	Limited warranty - lifetime
Environmental Parameters	Environmental Parameters
Min Operating Temperature	-20 Â°C
Max Operating Temperature	65 Â°C
Humidity Range Operating	0 - 95% (non-condensing)
