TRENDnet TI-RP262I / Industrial / switch / Managed / 24 x 10/100/1000 (PoE+) + 2 x SFP / rack-mountable / PoE+ / TAA Compliant | TI-RP262i
Please sign in so that we can notify you about a reply
Special Features
- 24 x Gigabit PoE+ ports
- 2 x SFP slots
- Supports 100/1000Base-FX fiber SFP modules
- 685W PoE power budget
- PoE alive check restarts unresponsive PoE powered devices
- 52Gbps switching capacity
- Hardened IP30 rated metal housing
- Operating temperature range of -40° - 70° C (-40° - 158° F)
- Supports LACP, STP/RSTP, VLAN, and IGMP Snooping
- IEEE 802.1p QoS with queue scheduling support
- CLI (Console / Telnet / SSH), Web (HTTP / HTTPS), SNMP v1 / 2c / 3 management
- IGMP Snooping / MVR support
- 802.1p / DSCP / Queue Scheduling (SPQ / WRR) QoS support
- Bandwidth control per port
- Supports Ethernet Ring Protection Switching (ERPS)
- 19" rack mountable metal housing with included mounting kit
- Multiple inputs provide redundant power with overload current protection
Product Specification
| Device Type | Switch - 26 ports - Managed |
| Enclosure Type | Rack-mountable 1U |
| Subtype | Fast Ethernet |
| Ports | 24 x 10/100/1000 (PoE+) + 2 x SFP |
| Power Over Ethernet (PoE) | PoE+ |
| Performance | Switching capacity: 52 Gbps |
| MAC Address Table Size | 8K entries |
| Jumbo Frame Support | 10KB |
| Remote Management Protocol | SNMP 1, Telnet, SNMP 3, SNMP 2c, HTTP, HTTPS, SSH, CLI |
| Features | VLAN support, IGMP snooping, Syslog support, store and forward, SNTP support, Spanning Tree Protocol (STP) support, Quality of Service (QoS), LLDP support, Multicast VLAN Registration (MVR), Strict Priority Queuing (SPQ), Ethernet Ring Protection Switching (ERPS), 4KV ESD Protector (contact discharge), 8KV ESD Protector (air-gap discharge), Weighted Round Robin (WRR), 1KV surge protection, Rapid Reconfiguration of Spanning Tree (RSTP) |
| Compliant Standards | IEEE 802.3u, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.1ab (LLDP), IEEE 802.3at, IEEE 802.3az, IEEE 802.1AX |
| Status Indicators | Link/activity |
| Expansion / Connectivity | Expansion / Connectivity |
| Interfaces | 24 x 1000Base-T RJ-45 PoE+ - 30 W ¦ 1 x console RJ-45 management |
| Expansion Slots | 2 (total) / 2 (free) x SFP (mini-GBIC) |
| Miscellaneous | Miscellaneous |
| Cables Included | 1 x serial cable |
| Rack Mounting Kit | Included |
| Compliant Standards | FCC, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, IP30 |
| TAA Compliant | Yes |
| Dimensions & Weight | Dimensions & Weight |
| Width | 44 cm |
| Depth | 31 cm |
| Height | 4.4 cm |
| Weight | 3.58 kg |
| Manufacturer Warranty | Manufacturer Warranty |
| Service & Support | Limited warranty - lifetime |
| Environmental Parameters | Environmental Parameters |
| Min Operating Temperature | -40 °C |
| Max Operating Temperature | 70 °C |
| Humidity Range Operating | 0 - 95% (non-condensing) |
Features - Trendnet - TI-RP262i
General
24-Port
More Details
Product Code
04:399748
EAN Code
0710931161700
Manufacturer
Trendnet
