Ubiquiti UACC-ETH-SP-DIN Ethernet Surge Protection DIN Rail 10GbE PoE 20kA Indoor Surge Protector

Brand:
Ubiquiti
Ubiquiti UniFi Surge protector (DIN rail UACCETHSPDIN
Ubiquiti UACC-ETH-SP-DIN Ethernet Surge Protection DIN Rail 10GbE PoE 20kA Indoor Surge Protector
€48 inc. VAT
Buy
UACC-ETH-SP-DIN
€40.34
€48.00 inc. VAT
Ships from EU stock: 10 item(s)
+ −
Add to wish list Ask a question
Product Code
04:547589
EAN Code
0810177161844
Manufacturer
Ubiquiti
Quick Specs
Protection
20 kA · 90V GDT
Data
Up to 10 GbE · PoE pass
Mounting
DIN rail · indoor
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

UISP Ethernet Surge Protection — DIN Rail

UACC-ETH-SP-DINUp to 10 GbE · PoE support20 kA dischargeBidirectional · indoor

The Ubiquiti Ethernet Surge Protection DIN (part number UACC-ETH-SP-DIN) is an indoor, DIN-rail-mounted inline surge protector that shields network equipment on copper runs entering the building. It protects data lines up to 10 Gbps, passes PoE through untouched, and absorbs surges with a 20 kA discharge capacity — double the rating of the classic outdoor ETH-SP-G2. Typically in stock with fast delivery across Cyprus.

Compatibility note: For indoor installation on a DIN rail (or wall) — typically in the distribution cabinet where an outdoor run terminates. Proper earthing/grounding is essential for the gas discharge stage to work; protection is bidirectional, guarding both the switch side and the field side.

Key Features


10 GbE + PoE transparent
Protects multi-gig links up to 10 Gbps with just 1.0 pF added capacitance, and passes PoE through — including high-power lines — without interfering.

20 kA surge discharge
Gas discharge stage with 90V DC spark-over and 20 kA current handling absorbs induced lightning transients from 100 V/s up to 1 kV/μs rise times.

Rack-cabinet native
Polycarbonate and SGCC steel housing clips onto standard DIN rail at 89 × 25.5 × 37.4 mm and 74 g, keeping surge protection tidy inside the enclosure.

Technical Specifications

Identification
Part Number UACC-ETH-SP-DIN
EAN / GTIN 0810177161844
MPN UACC-ETH-SP-DIN
Protection
Data line protection Up to 10 Gbps, bidirectional
PoE support Yes — passes PoE through
Discharge current 20 kA
DC spark-over 90V @ 100V/s
Max impulse spark-over 600V @ 1 kV/μs
Insulation 1 GΩ @ 50V · max capacitance 1.0 pF @ 1 MHz
Physical & Environment
Interfaces 2× RJ45 female
Dimensions 89 × 25.5 × 37.4 mm
Weight 74 g
Materials Polycarbonate, SGCC steel
Mounting DIN rail (indoor)
Operating temperature -40 to +80°C

Frequently Asked Questions

Where should the UACC-ETH-SP-DIN be installed?
Indoors, at the point where an outdoor Ethernet run enters the cabinet — clipped to the DIN rail and properly earthed. For the device end on the mast, pair it with the outdoor ETH-SP-G2.
Does it slow down my network or affect PoE?
No. It is rated for links up to 10 Gbps with negligible added capacitance, and PoE (including high-power) passes through normally.
What is the difference from the ETH-SP-G2?
The G2 is an outdoor, drip-loop unit rated 1 Gbps and 10 kA+; the DIN version is an indoor rail-mount rated up to 10 GbE with 20 kA discharge. Best practice uses one at each end of exposed runs.
What do I need to know before buying?
It needs a solid ground connection to divert surge energy, and you should budget one protector per exposed cable run.
Singular Expert Insight
Surge damage rarely stops at the first device — an induced spike on a rooftop run can take out the switch port and everything on the same PSU. One DIN protector per incoming run is cheap insurance for a whole rack, especially paired with an outdoor unit at the antenna end. Protect the powered side too via quality PoE gear from our network switches range.

Buyer’s Guide

Buy it if
you terminate outdoor Ethernet runs in an indoor cabinet and want 10 GbE-rated, PoE-transparent, 20 kA surge protection on the rail.
Skip it if
the protector must live outdoors at the device — use the weatherproof ETH-SP-G2 there instead.
Also consider
the ETH-SP-G2 for the mast end, or fiber isolation (F-POE-G2 / UACC-AE) where galvanic isolation is preferred.
