Ubiquiti 10G CWDM SFP+ Module — 1270 nm, 20 km
10 Gbps over Single-ModeCWDM 1270 nm ChannelDuplex LC UPCUp to 20 km Reach
The Ubiquiti UACC-OM-SFP10-1270 (EAN 0810084694695) is a 10 Gbps CWDM SFP+ transceiver on the 1270 nm channel, built to multiply the capacity of a single-mode fiber pair: with a passive CWDM mux/demux, up to eight or more 10G links share the same physical fiber, each on its own colour of light. It reaches up to 20 km over duplex LC UPC single-mode fiber while drawing just 1.2 W — the standard tool for ISPs and campuses that own limited dark fiber. Typically in stock with fast delivery across Cyprus.
Compatibility note: CWDM modules work in SAME-WAVELENGTH PAIRS: install a 1270 nm module at each end of the link. To combine multiple wavelengths on one fiber pair you need a passive CWDM mux/demux (e.g. Ubiquiti UACC-CWDM-4 / UACC-CWDM-8) at both sites. Fits Ubiquiti SFP+ and SFP28 cages (runs at 10 Gbps). This is NOT a single-fiber BiDi module — it uses a duplex (two-fiber) LC UPC connection.
Key Features
Multiply Your Dark Fiber
Each CWDM wavelength is an independent 10G channel. Eight channels on one fiber pair means 80 Gbps of aggregate capacity without trenching a single new metre of fiber.
20 km Reach at 1.2 W
Long-reach optics cover metro and inter-village distances on standard G.652 single-mode fiber, with a wide 1260 - 1620 nm receive window and minimal power draw.
Clean Channel Discipline
The 1270 nm channel sits at the edge of the CWDM grid, letting you build organised wavelength plans across Ubiquiti's 12-channel module family (1270 - 1590 nm).
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
For a single point-to-point 10G link on plentiful fiber, a standard UACC-OM-SM-10G-S style module is simpler and cheaper. CWDM earns its cost when fiber is the scarce resource: with a UACC-CWDM-8 mux pair, one fiber pair carries eight of these modules' channels. Plan sibling channels (1290, 1310, 1330...) before ordering so the wavelength map stays tidy. Terminate the run into the SFP+ ports of your aggregation switches at each site.
Buyer's Guide
Buy it if
You run CWDM (or plan to) and need the 1270 nm channel for a 10G link up to 20 km on single-mode fiber.
Skip it if
You just need one simple 10G fiber link — standard 10G single-mode optics cost less and need no wavelength planning.
Also consider
Other UACC-OM-SFP10 channels (1290 - 1590 nm), UACC-CWDM-4/8 mux, or UACC-OM-SM-10G-S standard 10G optics.
Features - Ubiquiti - UACC-OM-SFP10-1270
More Details
Product Code
03:257496
EAN Code
0810084694695
Manufacturer
Ubiquiti
