Wantec 5722 2wIP E-Series Ethernet/PoE over Two-Wire Receiver, 1 RJ45, Screw-Terminal Link

Brand:
Wantec
Wantec 5722 Black 2wIP E-Series One-Port Two-Wire PoE Receiver
Wantec 5722 2wIP E-Series Ethernet/PoE over Two-Wire Receiver, 1 RJ45, Screw-Terminal Link
€219.79 inc. VAT
Buy
5722
€184.70
€219.79 inc. VAT
Ships from EU stock: 4 item(s)
+ −
Add to wish list Ask a question
Product Code
04:402695
EAN Code
4250367757222
Manufacturer
Wantec

Quick Specs

Role
Camera-side receiver
Network
10/100Base-T
Link
Two-wire screw terminals
PoE
IEEE 802.3af/at
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Wantec 5722 — Ethernet and PoE over Two Wires

2wIP E-Series572210/100Base-TPoE af/at

Wantec 5722 is the camera or client-side unit in a 2wIP E-Series installation. It receives the link from a compatible unit over two wires connected through screw terminals and provides one RJ45 Ethernet/PoE port for the endpoint.

Compatibility — check before buying:
Requires a compatible unit at the other end, such as switch-side 5720. No power adapter is included with 5722. Check line quality and length, V−/V+ polarity and the complete power budget before installation.

Key Features


Use a two-wire route
Carries Ethernet and power within the 2wIP E system, using a terminal-block link rather than BNC.

One endpoint port
The 10/100Base-T PoE af/at output serves a compatible camera or other endpoint within the available power budget.

Controls at the endpoint
Link indicators and the PoE switch assist checks at installation; Join is used for system pairing.

Technical Specifications

Identity
Model / SKU Wantec 2wIP E-Series 5722
EAN / GTIN 4250367757222
Role Camera/client-side one-port receiver; TX in the QIG
Colour Black
Ports and Ethernet
Ethernet port 1 × RJ45 Fast Ethernet with PoE output
Two-wire link 1 × plug-in screw-terminal block; V− / V+ polarity
DC connection 1 × DC jack, 56 VDC indicated
Ethernet standard 10/100Base-T, half/full duplex, auto-negotiation
PoE standards IEEE 802.3af / 802.3at
E-series output reference Up to 25.4 W; available power depends on line, distance and supply budget
E-series configuration
Required counterpart At least one compatible switch-side transmitter;5720 terminal-block model is listed by Wantec
Encryption 128-bit AES, E-series feature
Topologies E-series supports star, ring, daisy-chain and mixed configurations
Control / indicators Join button, PoE on/off switch; power, link, LAN/PoE LEDs
Environment and supply
QIG operating range −20 to +60 °C
Manufacturer recommended range −10 to +50 °C
Local power option 56 VDC /65 W power adapter shown as optional for 5722; not included
Ethernet cabling CAT5e or CAT6 UTP/STP; suitable two-wire link cable
Pack One 5722 unit and quick installation guide; power adapter only with 5720

What's in the Box

One Wantec 5722 unit
Quick installation guide

What Will Not Work

A complete link requires a compatible unit at the other end.
Available power and reach depend on cabling and supply; assess the specific line.

Frequently Asked Questions

Is a 56V/65W power adapter included?
No. The 5720/5722 guide includes the adapter with 5720 only and shows local power at 5722 as optional.
Is one 5722 enough to connect a camera over two wires?
A compatible switch-side unit is also required. Wantec lists 5720 as the corresponding terminal-block transmitter.
Does the port support Gigabit Ethernet?
The specified port is 10/100Base-T Fast Ethernet. Plan the network traffic around that limit.
Singular Expert Insight
For an existing-line upgrade, assess the route and the camera’s power demand first. Then select the compatible switch-side unit and verify the actual operating conditions. Ask us to plan the link and power requirements

Buyer’s Guide

Buy it if

You are extending a compatible2wIP E system to one Ethernet/PoE endpoint with a terminal-block link.

Skip it if

You need Gigabit, a BNC connection or a standalone power adapter.

Also consider

The 5720 counterpart, cable quality and the total PoE load.
