Wera 840/0 Hex-Plus Micro Bit 1.3 x 30mm for Hexagon Socket Screws 4mm Hex Drive Precision
Brand:
Wera
Wera 840/0 Hex-Plus Micro Bit 1.3 x 30mm for Hexagon Socket Screws 4mm Hex Drive Precision
€3.44 inc. VAT
05058109001
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
Wera 840/0 Hex-Plus Micro — a 1.3 mm hexagon bit on a 4 mm micro drive
1.3 mm across flats4 mm hexagon driveHex-Plus profile30 mm long
This is a single Wera 840/0 Micro bit, 1.3 mm across flats and 30 mm long, for internal hexagon socket screws at the small end of the scale. It uses the Hex-Plus profile, which increases the contact area inside the screw socket so the load is carried on the flats rather than concentrated on the six corners — the difference between a screw you can undo again and one that has rounded out. Critically, the drive shank is 4 mm hexagon, Wera’s micro standard, not the usual 1/4″. The blade is 2.6 mm in diameter, which is what allows it to reach into recessed sockets on small assemblies. Typically in stock with fast delivery across Cyprus.
Compatibility — check before buying:
The drive is 4 mm hexagon, not 1/4″ (6.35 mm). This bit will not fit a standard bit holder, screwdriver handle or drill chuck adapter — it requires a Wera micro bit holder or micro screwdriver handle with a 4 mm take-up. That is the single most important thing to check before ordering. This is a single bit: no holder, no handle and no case are included. Wera cites no DIN or ISO standard for the 4 mm micro drive, so we do not quote one, and the bit carries no Z, TZ or BTZ marking — there is no torsion zone.
Best For
✓ Electronics, optics and instrument repair
✓ Model making and fine mechanical work
✓ Small hexagon socket screws that round out easily
✓ Anyone already using Wera 4 mm micro drivers
Key Features
Hex-Plus on a very small hexagon
The smaller the hexagon, the less material there is in the corners of the socket and the easier it rounds. Hex-Plus spreads contact across the flats instead, which is exactly where it matters most at 1.3 mm.
4 mm micro drive
Wera’s micro bit system uses a 4 mm hexagon shank rather than 1/4″. The result is a much slimmer tool that reaches into recesses a standard bit and holder physically cannot enter.
30 mm of reach on a 2.6 mm blade
The bit is 30 mm long with a 2.6 mm blade diameter. That combination gets down into a countersink or a recessed boss on a small assembly without the shank fouling the surrounding material.
A replaceable single bit
Sold individually, so you can replace exactly the size you have worn or lost rather than buying a whole set again. It fits any Wera micro holder with a 4 mm take-up.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight
At this size the failure mode is always the same: the hexagon socket rounds before the screw moves. There is simply not much metal in the corners of a 1.3 mm socket, and a conventional hex bit loads exactly those corners. Hex-Plus shifts the contact onto the flats, which is why it matters more on micro sizes than it does at 6 or 8 mm. The one thing to confirm before you order is the drive: 4 mm hexagon, so it belongs in a Wera micro handle and will not go anywhere near a standard 1/4″ holder. Browse our range in Cable Tools & Testers, or the wider Cables section for installation kit.
Buyer’s Guide
Buy it if
You work on small hexagon socket screws with a Wera micro handle and want the Hex-Plus profile to keep the sockets intact, or you need to replace one worn size.
Skip it if
You have a standard 1/4″ bit holder — this will not fit it — or you need a complete set with a handle included.
Also consider
A Wera micro bit holder or Kraftform Micro handle with a 4 mm take-up, other sizes in the 840/0 Micro range, or a 1/4″ Hex-Plus bit if your screws are larger.
Features - Wera - 05058109001
More Details
Product Code
04:544926
EAN Code
4013288234544
Manufacturer
Wera
