Wera Kraftform Kompakt Stubby Magazine RA 4 Ratchet Screwdriver 6 Bits Phillips Slotted Square-Plus

Brand:
Wera
Wera Kraftform Kompakt Stubby magazine RA 4
Wera Kraftform Kompakt Stubby Magazine RA 4 Ratchet Screwdriver 6 Bits Phillips Slotted Square-Plus
€43.11 inc. VAT
Buy
05008893001
€36.23
€43.11 inc. VAT
Ships from EU stock: 2 item(s)
Product Code
04:545012
EAN Code
4013288233950
Manufacturer
Wera

Quick Specs

Bits
6 x 25 mm tough Z
Return Angle
9 degrees
Blade
None, stubby bit mount
Weight
155 g
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

Wera Kraftform Kompakt Stubby Magazine RA 4 — 6 Bits

Stubby Ratchet Driver9° Return AngleSwivelling Bit MagazineRing Switch with 0 Position

The Kraftform Kompakt Stubby magazine RA 4 is a ratcheting bit driver with no blade at all: the bit mounts straight into the head, so the whole tool is short enough to work where nothing longer will fit. Six bits — Phillips PH 1 and PH 2, slotted 1 x 5.5 and 1.2 x 6.5, and Square-Plus #1 and #2 — live in a swivelling magazine built into the handle. A fine-toothed ratchet gives a 9° return angle, and the ring switch works the way you expect: turn it clockwise for clockwise driving, the other way to reverse, or set it to 0 to deactivate the ratchet and drive rigidly. A strong permanent magnet holds the bit in the short mount. Typically in stock with fast delivery across Cyprus.

Compatibility — check before buying:
Wera counts only the six bits — the handle, ratchet and magazine are the carrier tool and are not in the count. Because there is no blade, the tool cannot reach a recessed fastener at all: it is a short-access driver, not a general one. Profile coverage is Phillips, slotted and Square-Plus only — no TORX and no hex. The magazine holds exactly six, so it is full as supplied. Not insulated, not VDE-approved, not impact-rated. Check the article number when comparing prices: the older 05008886001 has the same product name but is discontinued; this is the current version, EAN 4013288233950, 155 g.

Best For

✓ Cabinets, engine bays and appliance interiors
✓ Work where a normal driver cannot be swung
✓ Bag and toolbox carry
✓ Square-Plus and Robertson hardware

Key Features


No Blade, Maximum Short Access
The bit mounts directly in the head, so the tool is as short as a ratcheting driver can be. That is the entire design brief — it goes where a driver with any blade at all cannot enter.

Swivelling Six-Bit Magazine
A magazine built into the handle swivels open to give the six bits and holds them securely when closed, so the driver arrives complete with nothing loose to lose in a cabinet.

Ring Switch with a 0 Position
Turn the ring clockwise and the ratchet drives clockwise; turn it the other way and it reverses. The 0 position deactivates the ratchet so the tool works rigidly for precise work and final tightening.

9 Degree Return Angle
A fine-toothed ratchet needing only a 9° swing to pick up the next tooth, plus free spinning when the screw offers no resistance — which matters most in exactly the cramped spaces this tool is made for.

Technical Specifications

Identification
Brand Wera
Article number 05008893001
Series Kraftform Kompakt Stubby magazine RA 4
Type Stubby ratcheting bitholding screwdriver with bit magazine
EAN 4013288233950
Set Contents (6 pieces, all bits)
Phillips 1x 851/1 Z PH 1 x 25 mm, 1x 851/1 Z PH 2 x 25 mm
Slotted 1x 800/1 Z 1 x 5.5 x 25 mm, 1x 800/1 Z 1.2 x 6.5 x 25 mm
Square-Plus 1x 868/1 Z # 1 x 25 mm, 1x 868/1 Z # 2 x 25 mm
Bit type Tough Z bits, no torsion zone
Also Supplied (not in the 6)
Screwdriver 1x Kraftform Kompakt Stubby magazine RA 4 with integrated ratchet and magazine
Storage None — the in-handle magazine is the storage
Screwdriver Detail
Drive 1/4 inch hexagon, short bit mounting, no blade
Ratchet Fine toothing, integrated in the handle
Return angle 9 degrees
Control Ring switch: clockwise, anti-clockwise, 0 (ratchet deactivated)
Free spinning Yes, when the screw offers no resistance
Bit retention Strong permanent magnet
Magazine Swivelling, 6 bits, secure retention
Handle Two-component Kraftform with hard and soft zones, non-roll feature
Physical
Dimensions 115 x 60 x 40 mm
Weight 155 g
Bit length 25 mm
Country of origin Czech Republic
Usage Limits
Blade None — cannot reach recessed fasteners
Profiles not included TORX, hex, Pozidriv
Torsion zone None — plain Z bits
Insulation Not insulated, not VDE-approved
Impact use Not rated
Warranty
Warranty 1-Year Warranty (Singular)

Frequently Asked Questions

Is it six pieces or seven?
Six. Wera counts only the bits; the ratcheting handle with its magazine is the carrier tool and is not in the headline figure. Note that Wera is not consistent about this — on the Kompakt 27 XL SHK 1 the screwdriver is counted.
Why is there no blade?
Because the point of the tool is short access. The bit mounts straight into the head, making it as compact as a ratcheting driver can be. The trade-off is that it cannot reach anything down a recess.
What is Square-Plus?
Wera name for the square (Robertson-type) drive, standard on North American and Canadian hardware. This tool carries #1 and #2.
I have seen this product with a different article number. Which is current?
This one. Article 05008893001, EAN 4013288233950, 155 g is the current version. The older 05008886001 carries the same product name but is discontinued, and several retailers still list it.
Singular Expert Insight
There is a specific job this tool exists for: the screw you can see, can reach with a fingertip, and cannot get any normal driver onto. No blade at all is an unusual answer and it works, but be honest about the cost — anything down a recess is out of reach entirely, so this lives alongside a normal driver rather than replacing one. The 0 position is worth knowing about too: in a tight space a ratchet is fast, but the last quarter turn is better done rigid. Browse our Cable Tools - Testers category for more Wera hand tools, or the wider Cables range for related workshop supplies.

Buyer’s Guide

Buy it if

You regularly meet screws in spaces too tight for a normal driver and want a ratchet with six bits stored inside it.

Skip it if

You need to reach recessed fasteners, want TORX or hex bits, or need a torsion zone or an impact rating.

Also consider

The Kraftform Kompakt 27 RA 1 (05051517001) for a full-length ratcheting driver with BiTorsion bits, or the Kompakt 28 RA 1 (05051519001) for a telescopic blade.
