WD Ultrastar DC HC555 18TB Enterprise HDD, 3.5-Inch SAS 12Gb/s, 7200 RPM, 512MB Cache, CMR, Helium, SE
Brand:
Western Digital
WD Ultrastar DC HC555 18TB Enterprise HDD, 3.5-Inch SAS 12Gb/s, 7200 RPM, 512MB Cache, CMR, Helium, SE
€1775.15 inc. VAT
0B47747
Delivery
Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
Trusted Tech Choice
Buying Benefits
Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support
Please sign in so that we can notify you about a reply
WD Ultrastar DC HC555 18TB — SAS Helium HDD for Servers and Storage Arrays
18 TBSAS 12Gb/s7200 RPM, 512 MBCMR + HelioSeal
The Western Digital Ultrastar DC HC555 18TB (part number 0B47747) is a 3.5-inch enterprise hard drive with a 12Gb/s SAS interface, 7200 RPM and 512 MB cache, built for servers, storage arrays and data-centre workloads. It uses conventional magnetic recording (CMR) in a sealed HelioSeal helium enclosure and is rated for 550 TB per year with 2.5 million hours MTBF.
0B47747 is the SE (standard, non-encrypting) version: it offers sanitize overwrite but no self-encryption. Choose a different part number if your policy requires SED or TCG encryption.
Before you order: This is a SAS drive. It needs a SAS HBA or RAID controller and a SAS backplane — it will not work on SATA-only ports or SATA-only NAS bays.
What's in the Box
- 1 × WD Ultrastar DC HC555 18TB SAS HDD (bare drive)
- No cables, screws or carrier — WD does not publish retail package contents
What It Means in Practice
- High capacity per bay with CMR recording — predictable write performance for RAID, unlike SMR drives.
- Suits backup targets, object storage, video archives and capacity tiers in SAS arrays.
- Uses about 0.32 W per TB, helping keep power and cooling in check in dense servers.
- Sustained transfer up to 269 MB/s.
What Will Not Work
- It will not work on SATA ports or SATA-only controllers and NAS bays.
- It is not a self-encrypting drive (SE version) — for SED order 0B48713.
- It is not a SATA drive — the 18TB SATA SE version is 0B48723.
- WD does not publish the sector format (512e/4Kn) for this part number; ask us if your controller is sensitive to it.
Key Features
CMR + HelioSeal
Conventional recording in a helium-sealed enclosure for capacity and efficiency.
SAS 12Gb/s
Enterprise SAS interface for HBAs, RAID controllers and dual-path backplanes.
550 TB/year workload
Rated for continuous data-centre duty with 2.5M hours MTBF.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
The HC555 18TB is a solid capacity drive for SAS servers that need predictable CMR performance. Confirm your controller and backplane are SAS before ordering; compare alternatives in our enterprise HDDs.
✓ Buy it if you are filling SAS bays in a server or storage array and want 18TB CMR drives.
✕ Skip it if your system only has SATA ports, or you need a self-encrypting drive.
→ Also consider 0B48723 (18TB SATA SE) for SATA systems or 0B48713 for SAS with encryption.
Not sure it fits your setup? Send us the model of your rack, switch or device and we will check compatibility before you order.
Features - Western Digital - 0B47747
Form Factor
- 3.5"
Interface
- SAS
More Details
Product Code
CL67498
EAN Code
0829686009356
Manufacturer
Western Digital
Technical specifications
Capacity
18TB
