Zebra DS9300 Series DS9308 / Standard Range (SR) / barcode scanner / desktop / 3050 mm / sec / decoded / interface cable required | DS9308-SR00004ZZWW

Ask a question
DS9308-SR00004ZZWW
Product CodeV36C436 ManufacturerZebra Technologies
Zebra DS9300 Series DS9308 / Standard Range (SR) / barcode scanner / desktop / 3050 mm / sec / decoded / interface cable required | DS9308-SR00004ZZWW Description The DS9300 Series is the little presentation scanner with big functionality. With its compact form factor and stylish...
226.14
269.11  inc. VAT
Standard DeliveryStandard delivery within 4 to 8 business days.Express DeliveryExpress delivery within 2 to 3 business days.
+
Standard DeliveryStandard delivery within 4 to 8 business days.Express DeliveryExpress delivery within 2 to 3 business days.

Zebra DS9300 Series DS9308 / Standard Range (SR) / barcode scanner / desktop / 3050 mm / sec / decoded / interface cable required | DS9308-SR00004ZZWW

Description

The DS9300 Series is the little presentation scanner with big functionality. With its compact form factor and stylish aesthetics, the DS9300 Series fits anywhere - from trendy boutiques to convenience stores with limited real-estate at the checkout counter.

Zebra DS9300 Series DS9308 / Standard Range (SR) | DS9308-SR00004ZZWW

Special Features

  • Scan it all
  • Innovative-driven design
  • Maximum durability and reliability

Product features

  • Scan it all
    With an fast microprocessor, high-resolution megapixel sensor and exclusive imaging technology, the DS9300 Series instantly captures barcodes in virtually any condition, on any media.
  • Innovative-driven design
    With a near-zero footprint, there's always room for the DS9300 Series, no matter how space-constrained your counters may be. Recessed LEDs are virtually invisible and automatically dim when not in use - reducing eye annoyance. The scanner's ratcheting base offers four positions for convenient scanning, and its frictionless design won't wear out.
  • Maximum durability and reliability
    Drops, dust and spills are no problem for the DS9300 Series. It's built to handle drops to concrete and tumbles. And thanks to IP52 sealing and a opto-mechanical layout that includes a concealed beeper hole with elevated circuitry and cable connector, even the base is spill proof.


Product Specification

Type Barcode scanner - desktop
Colour Midnight black
Interface Type Interface cable required
Minimum Bar Width 3 mil
Scan Element Type Red LED
Sensor Resolution 1280 x 800
Light Source Wave Length 617 nm
Scan Mode Single-pass
Scan Speed 3050 mm / sec
Max Working Distance 27.9 cm
Skew (Degrees) 60
Pitch (Degrees) 60
Print Contrast Signal (PCS) 15%
Decode Capability Code 93, Matrix 2 of 5, Code 39, UCC/EAN-128, ISBT 128, NW-7, IATA, ISBN, coupon code, GS1 DataBar, MaxiCode, Aztec code, Bookland, Code 39 Full ASCII, EAN/JAN-8, EAN/JAN-13, UPC-A, UPC-E, Discrete 2 of 5, MicroPDF417, Italy Pharmacode, Codabar, Code 128, Code 11, UPC, Interleaved 2 of 5, Postnet, PDF417, MSI-Plessey, ITF, PLANET, TLC39, Australian Post, Japanese Post, Kix (Netherlands) Post, IATA 2 of 5, UPC-E1, UPC-A/EAN-13 with Extended Coupon Code, EAN-UCC Composite, MacroPDF417, ISSN, Code 128 Full ASCII, Code 39 Trioptic, UK Post, Royal Mail, 4-State postal code, CC-B, GS1 DataBar Omnidirectional, GS1 DataBar Expanded Stacked
TTL Decoding Decoded
Connectivity Technology Wired
OK Notification Beeper, LED indicator
Features ESD (electrostatic discharge) safe, deactivation of EAS tag
Compliant Standards EN 61000-4-2, IP52, EN 50581:2012, EN 62471:2008, EN 61000-3-3:2013, EN 55024:2010, FCC CFR47 Part 15 B Class B, EN 55024:2010+A1:2015, EN 62368-1, IEC 62368-1, ICES-003 issue 6 Class B, EN 55032:2012+AC:2013 Class B, EN 61000-3-2:2014 Class A, IEC 62471-1:2006, EN 55032:2015+AC:2016 Class B, EN 55035:2017
Power Device Power adapter
Electric Current Required 135 mA (standby), 335 mA (typical)
Width 8.6 cm
Depth 8.3 cm
Height 14.5 cm
Weight 318 g
Service & Support Limited warranty - 3 years
Min Operating Temperature 0 °C
Max Operating Temperature 50 °C
Humidity Range Operating 5 - 95% (non-condensing)
Drop Specification 1.5 m to concrete

Features - Zebra Technologies - DS9308-SR00004ZZWW

More Details
Product Code:
V36C436
EAN Code:
-
Manufacturer:
Zebra Technologies
