Zebra DS4608-HD High Density 1D/2D Corded Barcode Scanner Only, Twilight Black

Brand:
Zebra
Zebra DS4608-HD Twilight Black Corded 2D High Density Barcode Scanner Only
Zebra DS4608-HD High Density 1D/2D Corded Barcode Scanner Only, Twilight Black
€242.05 inc. VAT
Buy
DS4608-HD00007ZZWW
€203.40
€242.05 inc. VAT
Ships from EU stock: 15 item(s)
+ −
Add to wish list Ask a question
Product Code
V36C333
EAN Code
8596375197657
Manufacturer
Zebra

Quick Specs

Engine
High Density 1D / 2D
Minimum element
Code 39 2 mil / Data Matrix 4 mil
Connection
Corded multi-interface
Package
Scanner only; cable separate
Delivery

Order Today...
Ships...
Delivery...
ℹ️ Large or fragile items (e.g. monitors) may require extra handling time. We'll keep you informed.
Payment options
✓ Bank Deposit
Secure checkout with flexible payment methods
Trusted Tech Choice
Buying Benefits Verified
Competitive EU pricing
Delivered to Cyprus from EU stock
Local warranty support

High Density optics for small codes, supplied as a scanner only

High Density1D + 2DCable separate

The DS4608-HD is a corded area imager for small, dense labels as well as common 1D/2D codes. Aim at the intended label and send its data into a compatible host application. This Twilight Black configuration is the scanner only: select the host cable separately. HD changes the close-range optics, not the wired nature of the reader.

Before you order:
HD means High Density, not long range. The reference minimum is 2 mil Code 39 / 4 mil Data Matrix; actual reading depends on code quality and conditions. The HD UPC 13 mil range is 0–45.7 cm, unlike the SR reference of 0–71.1 cm. Cable and stand are not included. EAS support is optional; do not assume fitted activation hardware.

What's in the Box

  • DS4608-HD00007ZZWW scanner, Twilight Black

What Will Not Work

  • Wireless Bluetooth operation
  • Connection without the separately selected host cable
  • Driver licence parsing options from DL/HL versions are not assumed

Key Features


Small label detail
HD resolution targets smaller code elements; test your actual label dimensions and print quality before deployment.

Common and specialised formats
The engine reads QR, Data Matrix, stacked/postal codes and OCR formats listed in the specifications. Application integration still determines how the data is used.

Manage a wired fleet
123Scan, Scanner SDK and SMS support setup and management. IP52 and repeated-drop/tumble ratings support daily handling.

Technical Specifications

Identification
Manufacturer SKU DS4608-HD00007ZZWW
EAN / GTIN 8596375197657
Exact configuration
Host cable Not included; select for interface and power requirements
Stand Not included
Scanning
Engine High Density 1D/2D area imager
Processor 800 MHz
Sensor 1280 × 800 pixels
Aiming / illumination 617 nm amber LED circle / 2 × 660 nm red LEDs
Field of view 31.6° H × 22.6° V
Minimum contrast 15%
Skew / pitch / roll ±60° / ±60° / 0–360°
HD minimum resolution Code 39: 2 mil / Data Matrix: 4 mil
1D examples Code39/128/93/11, Codabar, MSI, UPC/EAN, I2of5, GS1 DataBar, Base32
2D examples PDF417, MicroPDF417, Composite, TLC39, Aztec, Data Matrix, MaxiCode, QR/MicroQR, HanXin, Postal, SecurPharm, DotCode, Dotted DataMatrix
OCR OCR-A, OCR-B, MICR, US Currency
Image export Bitmap, JPEG, TIFF
Typical HD decode ranges
Code39, 3 mil 3.3–15.2 cm
Code39, 5 mil 0.3–29.2 cm
Code39, 20 mil 1.5–73.7 cm
Code128, 5 mil 4.3–12.7 cm
PDF417, 6.7 mil 1.5–23.6 cm
UPC, 13 mil 0–45.7 cm
Data Matrix, 10 mil 0.5–24.1 cm
QR, 20 mil 0–34.3 cm
Range conditions Print resolution, contrast and ambient light dependent
Interfaces and power
Host interfaces USB, RS232, Keyboard Wedge, TGCS IBM46XX RS485
USB certification USB 2.0 Full Speed
Keyboard layouts Over 90
Input voltage 4.5–5.5 VDC
Operating current 340 mA typical at 5 V
Standby current 150 mA typical at 5 V
Feedback Direct Decode Indicator, LEDs, adjustable beeper
Physical and environmental
Colour Twilight Black
Dimensions H × W × D 165 × 67 × 98 mm
Weight 161.9 g
Protection IP52
Drop specification Multiple 1.8 m drops to concrete
Tumble specification 2000 tumbles at 0.5 m
Operating / storage temperature 0–50 °C / −40–70 °C
Humidity 5–95% RH, non-condensing
ESD ±15 kV air / ±8 kV direct and indirect
Ambient light 0–107000 lux
Management tools 123Scan, Scanner SDK, SMS
Manufacturer term 5 years for DS4608 defects in materials/workmanship, from shipment, Zebra terms apply

Frequently Asked Questions

Is HD always better than SR?
No. HD targets denser labels; SR can offer more reach on larger common codes. Compare the exact label and decode table.
Can I connect it straight out of this box?
A suitable host cable must be selected separately. This scanner-only SKU does not include the USB kit cable or a stand.
Singular Expert Insight
Choose this HD reader when small dense labels are the verified requirement and you want to choose the host cable yourself. If you need a ready USB package, compare the exact HD USB kit; if reach matters more than density, compare SR using the same barcode size. Compare barcode scanners

Buyer’s Guide

✓

Buy it if

 Small dense codes justify HD optics and you will choose a cable.
✕

Skip it if

 You expect a bundled USB cable, stand or cordless operation.
→

Also consider

 The HD USB kit, or SR for larger labels where reach matters.
Send your label dimensions, sample codes and host model so we can check suitability.
