Zebra P1080383-011 — Cover Open / Head Up Sensor for ZD410, ZD420D/C, ZD620D
Direct thermal / cartridgeOriginal Zebra partZD410 · ZD420D/C · ZD620DService part
The Zebra P1080383-011 is the original cover open / head up sensor spare part for the Zebra ZD410, ZD420 Direct Thermal, ZD420 Cartridge and ZD620 Direct Thermal desktop label printers — the sensor that tells the printer its cover is open, so it stops printing and reports the condition instead of feeding labels.
Zebra lists it in the official spare-parts catalogues for these printers (Head Up Sensor in the ZD410 catalogue, Cover Open Sensor in the ZD420/ZD620 direct-thermal and cartridge catalogues). A failed sensor typically shows up as a printer that reports the head or cover open while it is closed, or does not react when it is opened.
Before you order: Zebra uses two different sensors in this family: P1080383-011 for ZD410, ZD420 Direct Thermal, ZD420 Cartridge and ZD620 Direct Thermal, and P1080383-044 for the thermal-transfer ZD420 and ZD620. Check the model on the printer label (a T in ZD420T/ZD620T means thermal transfer) before ordering. The newer ZD421 and ZD621 use different parts.
What's in the Box
- 1 × Zebra cover open / head up sensor (P1080383-011)
- No tools, cables or installation guide beyond what Zebra supplies with the kit
What It Means in Practice
- It is an internal part: fitting it means opening the printer, so it is best done by someone used to servicing Zebra desktop printers — we can arrange that for you.
- If the printer shows a head-open or cover-open error with the cover closed, clean the area and check the latch first; if the error stays, this sensor is the usual next step.
- Keeping a spare sensor on site avoids a printer being out of action for a small part.
What Will Not Work
- Zebra ZD420T and ZD620T thermal-transfer printers — they need P1080383-044.
- Zebra ZD421, ZD621 and ZD411 — Zebra uses different (P1112640-series) parts.
- Other Zebra series (GK, GX, ZT) or other brands.
Key Features
Original Zebra part
The part number listed in Zebra's own spare-parts catalogue for these printers.
Model-specific
Matches the ZD410 and direct-thermal/cartridge ZD420/ZD620 mechanism.
Restores safe stop
Lets the printer detect an open cover again and stop correctly.
Technical Specifications
Frequently Asked Questions
Singular Expert Insight · Buyer's Guide
Before replacing a sensor, rule out a dirty sensor area or a worn latch — they cause the same error. When the sensor has failed, the right part number matters: the ZD420/ZD620 family uses two sensors depending on print method. Browse our printer accessories and spare parts for printheads, platen rollers and cleaning supplies.
✓ Buy it if your ZD410 or ZD420D/C or ZD620D reports cover/head open errors that cleaning does not fix.
✕ Skip it if your printer is a thermal-transfer ZD420T/ZD620T, or a ZD421/ZD621.
→ Also consider P1080383-044 for the thermal-transfer ZD420 and ZD620.
Send us the printer model and serial number from the label on the back and we will confirm the right part before you order.
