Zyxel GS1100-10HP / Switch / unmanaged / 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP / desktop, wall-mountable / PoE+ (130 W) | GS1100-10HP-EU0102F

Product Features
- Green networking
The GS1100 series not only offers Gigabit Ethernet connectivity for advanced network applications, but also power-saving functions for better energy efficiency. Capable of dynamically adjusting power output according to traffic, active links and cable length, the GS1100 series can reduce energy consumption. - Fanless design
The complete GS1100 series comes in a fanless design that ensures silent operation in small or quiet office environments. The GS1100-10HP PoE model was specifically designed with an external power adapter that eliminates the need for an additional fan to cool down the device, making it perfect for quiet PoE deployments. - Gigabit to the desktop
The ZyXEL GS1100 series offers small offices optimal 8 / 10 / 16 / 24-port Gigabit connectivity. Additionally, the GS1100-10HP model is equipped with 2 extra SFP slots, supporting dual rate that enables fiber optic connections for long-distance deployments. With Gigabit network performance, the GS1100 series is the ideal solution for bandwidth-intensive applications such as high-resolution photo transmission, video / audio streaming and server farm connections. - Freedom of installation via PoE
The GS1100-10HP supports the PoE Plus standard to ease the installation of network devices in challenging spaces such as ceilings or walls. The low power supply per port allows the GS1100-10HP to power PoE-enabled WLAN APs, VoIP phones and IP surveillance cameras through cables without extra power adapters. This feature helps enterprises reduce installation time and cost when there are many such devices on the network. The GS1100-10HP has been designed with eight full PoE Plus ports, which makes it an ideal connectivity solution for high-density powered device deployments. In addition, the extra two SFP links on GS1100-10HP also easily extend networks to remote locations such as branch offices and warehouses for small- and medium-size businesses.
Special Features
- Non-blocking, wire-speed transmission
- Auto MDI / MDI-X support
- Fanless design for silent operation
- Jumbo frame support
Product Specification
Device Type | Switch - 10 ports - unmanaged |
Enclosure Type | Desktop, wall-mountable |
Subtype | Gigabit Ethernet |
Ports | 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP |
Power Over Ethernet (PoE) | PoE+ |
PoE Budget | 130 W |
Performance | Switching capacity: 20 Gbps ¦ Forwarding performance: 14.88 Mpps |
MAC Address Table Size | 8K entries |
Jumbo Frame Support | 9KB |
Features | Flow control, VLAN support, auto-uplink (auto MDI/MDI-X), Broadcast Storm Control, fanless, Energy Efficient Ethernet, 256KB packet buffer, Class of Service (CoS) |
Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az |
Status Indicators | Port status, power, PoE, link/activity |
Expansion / Connectivity | Expansion / Connectivity |
Interfaces | 8 x 1000Base-T RJ-45 PoE+ ¦ 2 x Gigabit LAN SFP |
Power | Power |
Power Device | External power adapter |
Voltage Required | AC 100-240 V (50/60 Hz) |
Power Consumption Operational | 156.1 Watt |
Miscellaneous | Miscellaneous |
Included Accessories | Wall mounting kit |
MTBF | 1,000,070 hours |
Compliant Standards | BSMI, ICES-003, FCC, RoHS, REACH, LVD, EMC Class B, RCM |
Dimensions & Weight | Dimensions & Weight |
Width | 25 cm |
Depth | 10.4 cm |
Height | 2.7 cm |
Weight | 730 g |
Manufacturer Warranty | Manufacturer Warranty |
Service & Support | Limited warranty - lifetime |
Environmental Parameters | Environmental Parameters |
Min Operating Temperature | 0 °C |
Max Operating Temperature | 50 °C |
Humidity Range Operating | 10 - 90% (non-condensing) |
Min Storage Temperature | -40 °C |
Max Storage Temperature | 70 °C |
